General Settings

Fluid-Structure Interaction Performed
yes
Source for FSI
This TCFD Case
Rotates with CFD Frame
rotating
Used CFD Patches
1:223
Number of Components [ ⁠–⁠ ]
1
Thermal Effects Considered
yes
Angular Velocity [ RPM ]
303360.

Material Description - material1

Used for Components
bullet-223-solid
Density [ kg/m3 ]
7800.00
Type
isotropic
Young Modulus [ GPa ]
210.000
Poisson Ratio [ ⁠–⁠ ]
0.300000
Heat Capacity [ J/(kg.K) ]
460.000
Heat Condactivity [ W/(m.K) ]
30.0000
Thermal Expansion [ 10^-6.m/(m.K) ]
13.0000

Solver

Parallel Processors [ ⁠–⁠ ]
32
Finite Element Order [ ⁠–⁠ ]
1
Nonlinear Governing Equation
no
Eigenmodes for Deformed Solid
no

Mesh Statistics - Component bullet-223-solid

Meshing Engine
NetGen
Meshing Time [ hh:mm:ss ]
00:01:47
Number of Points [ ⁠–⁠ ]
201911
Number of Elements [ ⁠–⁠ ]
1112586
Number of Surface Faces [ ⁠–⁠ ]
50872
Shortest Edge [ mm ]
6.10000 × 10-5
Longest Edge [ mm ]
3.04000 × 10-4
Minimal Angle Between Edges [ deg ]
19.6755
Maximal Angle Between Edges [ deg ]
125.763
Minimal Angle Between Faces [ deg ]
18.7064
Maximal Angle Between Faces [ deg ]
144.754

Run time information

Wall Time [ hh:mm:ss ]
00:03:13

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
25431
0.131045 [ mm ]
(0.0162721 -2.65127e-05 1.33031e-05)
Minimal Displacement Magnitude
1736
0 [ mm ]
(0.000275864 -0.000290355 0.000278693)
Maximal Displacement X
25431
0.130662 [ mm ]
(0.0162721 -2.65127e-05 1.33031e-05)
Minimal Displacement X
1624
-7.49026 × 10-4 [ mm ]
(0.000275864 0.00053594 0.000429124)
Maximal Displacement Y
2842
0.0278608 [ mm ]
(9.3954e-05 0.0026159 3.67519e-05)
Minimal Displacement Y
2746
-0.0273978 [ mm ]
(9.70306e-05 -0.0026183 2.20051e-05)
Maximal Displacement Z
2845
0.0279095 [ mm ]
(9.87759e-05 -0.000128059 0.00261705)
Minimal Displacement Z
2833
-0.0271481 [ mm ]
(9.69641e-05 -0.000177537 -0.00261222)
Maximal Displacement Axial
-293264432
1.90918 × 10-303 [ mm ]
(2.96439e-323 0 2.02468e-320)
Minimal Displacement Axial
8
0 [ mm ]
(0.000275864 -0.00019849 0.00209275)
Maximal Displacement Radial
0
6.74795 × 10-307 [ mm ]
(0 0 0)
Minimal Displacement Radial
0
6.74795 × 10-307 [ mm ]
(0 0 0)
Maximal Displacement Tangential
0
0 [ mm ]
(0 0 0)
Minimal Displacement Tangential
-408948800
6.74807 × 10-307 [ mm ]
(1.44787e+261 9.88131e-324 -2.96439e-323)
Maximal Von Mises Stress
1756
3361.76 [ MPa ]
(0.000275864 0.000378837 0.000152579)
Minimal Von Mises Stress
53295
0.237120 [ MPa ]
(0.0134219 -2.51749e-05 -0.000132259)
Maximal Principal Stress
1711
690.304 [ MPa ]
(0.000275864 -0.000474555 0.0001704)
Maximal Temperature
2195
930.212 [ K ]
(5.92489e-05 -0.000870858 0.00204801)
Minimal Temperature
5066
186.760 [ K ]
(0.00156187 0.00183736 -0.002129)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
2.03951 × 108
2272.91
0
2
2.15222 × 108
2334.88
0
3
4.21160 × 109
10328.7
0
4
9.39798 × 1010
48790.7
0
5
1.75524 × 1011
66679.0
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-3.85756 × 10-5
0.0194291
-0.0338807
1.46175 × 10-8
2.94303 × 10-4
1.68783 × 10-4
2
-1.71009 × 10-5
-0.0338800
-0.0194321
-5.27658 × 10-8
1.68783 × 10-4
-2.94303 × 10-4
3
-1.80345 × 10-6
-1.74023 × 10-5
9.60371 × 10-6
-8.80389 × 10-5
-5.63675 × 10-8
1.91567 × 10-7
4
-0.0467689
1.23574 × 10-5
7.60509 × 10-5
3.31328 × 10-9
-3.14332 × 10-7
-2.78683 × 10-8
5
4.97137 × 10-5
0.0222509
0.00818897
-1.15294 × 10-7
-2.49461 × 10-6
6.82241 × 10-6

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
1.48808 × 10-9
3.77490 × 10-4
0.00114790
2.13672 × 10-16
8.66142 × 10-8
2.84876 × 10-8
2
2.92442 × 10-10
0.00114785
3.77607 × 10-4
2.78423 × 10-15
2.84879 × 10-8
8.66141 × 10-8
3
3.25244 × 10-12
3.02842 × 10-10
9.22313 × 10-11
7.75085 × 10-9
3.17729 × 10-15
3.66978 × 10-14
4
0.00218733
1.52705 × 10-10
5.78374 × 10-9
1.09778 × 10-17
9.88045 × 10-14
7.76642 × 10-16
5
2.47145 × 10-9
4.95104 × 10-4
6.70592 × 10-5
1.32926 × 10-14
6.22310 × 10-12
4.65453 × 10-11
Total
0.00218733
0.00202045
0.00159257
7.75087 × 10-9
7.75087 × 10-9
7.75087 × 10-9

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
0.00220378
0.00220378
0.00220378
7.75123 × 10-9
7.75123 × 10-9
7.75123 × 10-9
