General Settings

Fluid-Structure Interaction Performed
yes
Source for FSI
This TCFD Case
Rotates with CFD Frame
static
Used CFD Patches
2:rotor
Number of Components
1
Thermal Effects Considered
no

Material Descrtiption - material1

Used for Components
Impeller
Density [ kg/m3 ]
7800.00
Type
isotropic
Young Modulus [ GPa ]
210.000
Poisson Ratio [ - ]
0.300000

Solver

Number of Parallel Threads
10
Finite Element Order
2
Nonlinear Governing Equation
yes
Eigenmodes for Deformed Solid
yes

Mesh Statistics - Component Impeller

Meshing time [ hh:mm:ss ]
00:02:40
Number of Points
157605
Number of Elements
749843
Number of Surface Faces
115798
Shortest Edge [ mm ]
5.30000 × 10-5
Longest Edge [ mm ]
0.00488000
Minimal Angle Between Edges [ deg ]
20.4845
Maximal Angle Between Edges [ deg ]
127.777
Minimal Angle Between Faces [ deg ]
18.0982
Maximal Angle Between Faces [ deg ]
151.081

Run time information

Wall time [ hh:mm:ss ]
00:25:17

Static Analysis

Quantity
Value
Node
X-coordinate
Y-coordinate
Z-coordinate
MaxDisplacement [ mm ]
4.51183 × 10-4
18731
0.0259704
0.00107977
0.00132855
MinDisplacement [ mm ]
0
1
-0.00160000
0
0.00800000
MaxDisplacementX [ mm ]
3.18289 × 10-4
125
3.68080 × 10-4
-0.0259974
0.00800000
MinDisplacementX [ mm ]
-3.46334 × 10-4
11941
-3.31120 × 10-4
0.0259683
0.00124938
MaxDisplacementY [ mm ]
3.23200 × 10-4
15991
0.0259984
-3.92228 × 10-5
0.00137893
MinDisplacementY [ mm ]
-3.17493 × 10-4
85
-0.0259693
-0.00126259
0.00800000
MaxDisplacementX [ mm ]
0
1
-0.00160000
0
0.00800000
MinDisplacementZ [ mm ]
-3.07050 × 10-4
14604
0.0259790
-0.00104586
0.00159200
MaxVonMisesStress [ MPa ]
10.7012
581345
0.00150383
8.02605 × 10-4
0.00800000
MinVonMisesStress [ MPa ]
1.01120 × 10-6
1022868
-0.00131426
8.97158 × 10-4
0.00900000
MaxPrincipalStressStress [ MPa ]
10.7869
581345
0.00150383
8.02605 × 10-4
0.00800000
MinPrincipalStressStress [ MPa ]
-3.61904
855376
0.00158890
1.72400 × 10-4
0.00808715

Run time information

Wall time [ hh:mm:ss ]
00:25:14

Static Analysis

Quantity
Value
Node
X-coordinate
Y-coordinate
Z-coordinate
MaxDisplacement [ mm ]
6.47245 × 10-4
18731
0.0259704
0.00107977
0.00132855
MinDisplacement [ mm ]
0
1
-0.00160000
0
0.00800000
MaxDisplacementX [ mm ]
4.35704 × 10-4
125
3.68080 × 10-4
-0.0259974
0.00800000
MinDisplacementX [ mm ]
-5.05190 × 10-4
12277
-2.85768 × 10-4
0.0259266
0.00117251
MaxDisplacementY [ mm ]
4.49099 × 10-4
16019
0.0259947
9.14672 × 10-5
0.00134953
MinDisplacementY [ mm ]
-4.31137 × 10-4
84
-0.0259998
9.99770 × 10-5
0.00800000
MaxDisplacementX [ mm ]
1.31863 × 10-4
198840
-0.0254628
0.00525555
0.00585352
MinDisplacementZ [ mm ]
-4.57083 × 10-4
166
0.0257258
-0.00376560
0.00800000
MaxVonMisesStress [ MPa ]
13.9576
581345
0.00150383
8.02605 × 10-4
0.00800000
MinVonMisesStress [ MPa ]
3.43453 × 10-7
1022868
-0.00131426
8.97158 × 10-4
0.00900000
MaxPrincipalStressStress [ MPa ]
13.2639
581345
0.00150383
8.02605 × 10-4
0.00800000
MinPrincipalStressStress [ MPa ]
-6.20866
261948
-7.34799 × 10-4
0.00146004
0.00789486

Run time information

Wall time [ hh:mm:ss ]
00:38:17

Static Analysis

Quantity
Value
Node
X-coordinate
Y-coordinate
Z-coordinate
MaxDisplacement [ mm ]
7.91686 × 10-4
14625
0.00114264
-0.0259677
0.00136306
MinDisplacement [ mm ]
0
1
-0.00160000
0
0.00800000
MaxDisplacementX [ mm ]
5.69225 × 10-4
10966
-1.52390 × 10-4
-0.0259995
0.00140007
MinDisplacementX [ mm ]
-5.65890 × 10-4
216
-0.00113393
0.0259752
0.00800000
MaxDisplacementY [ mm ]
6.00614 × 10-4
16743
0.0259839
2.87243 × 10-4
0.00129924
MinDisplacementY [ mm ]
-5.65575 × 10-4
85
-0.0259693
-0.00126259
0.00800000
MaxDisplacementX [ mm ]
0
1
-0.00160000
0
0.00800000
MinDisplacementZ [ mm ]
-5.37054 × 10-4
13741
-0.00109973
-0.0259767
0.00157322
MaxVonMisesStress [ MPa ]
17.9601
581345
0.00150383
8.02605 × 10-4
0.00800000
MinVonMisesStress [ MPa ]
2.65321 × 10-6
1121618
6.05822 × 10-4
0.00147319
0.00900000
MaxPrincipalStressStress [ MPa ]
17.1739
581345
0.00150383
8.02605 × 10-4
0.00800000
MinPrincipalStressStress [ MPa ]
-5.98944
855376
0.00158890
1.72400 × 10-4
0.00808715

Run time information

Wall time [ hh:mm:ss ]
00:25:23

Static Analysis

Quantity
Value
Node
X-coordinate
Y-coordinate
Z-coordinate
MaxDisplacement [ mm ]
9.04949 × 10-4
16779
0.0259729
-8.62180 × 10-4
0.00130478
MinDisplacement [ mm ]
0
1
-0.00160000
0
0.00800000
MaxDisplacementX [ mm ]
6.21001 × 10-4
125
3.68080 × 10-4
-0.0259974
0.00800000
MinDisplacementX [ mm ]
-6.80244 × 10-4
11941
-3.31120 × 10-4
0.0259683
0.00124938
MaxDisplacementY [ mm ]
6.59503 × 10-4
16743
0.0259839
2.87243 × 10-4
0.00129924
MinDisplacementY [ mm ]
-6.20045 × 10-4
85
-0.0259693
-0.00126259
0.00800000
MaxDisplacementX [ mm ]
3.91684 × 10-6
42927
-0.00326536
0.00231014
0.00258062
MinDisplacementZ [ mm ]
-6.33642 × 10-4
156
0.0227943
-0.0125066
0.00800000
MaxVonMisesStress [ MPa ]
20.5952
581345
0.00150383
8.02605 × 10-4
0.00800000
MinVonMisesStress [ MPa ]
1.77212 × 10-6
1022868
-0.00131426
8.97158 × 10-4
0.00900000
MaxPrincipalStressStress [ MPa ]
20.3541
581345
0.00150383
8.02605 × 10-4
0.00800000
MinPrincipalStressStress [ MPa ]
-7.07899
855376
0.00158890
1.72400 × 10-4
0.00808715

Run time information

Wall time [ hh:mm:ss ]
00:25:24

Static Analysis

Quantity
Value
Node
X-coordinate
Y-coordinate
Z-coordinate
MaxDisplacement [ mm ]
9.36657 × 10-4
16779
0.0259729
-8.62180 × 10-4
0.00130478
MinDisplacement [ mm ]
0
1
-0.00160000
0
0.00800000
MaxDisplacementX [ mm ]
6.54159 × 10-4
125
3.68080 × 10-4
-0.0259974
0.00800000
MinDisplacementX [ mm ]
-7.10794 × 10-4
11941
-3.31120 × 10-4
0.0259683
0.00124938
MaxDisplacementY [ mm ]
7.09549 × 10-4
17176
0.0259745
9.16164 × 10-5
0.00126487
MinDisplacementY [ mm ]
-6.52676 × 10-4
84
-0.0259998
9.99770 × 10-5
0.00800000
MaxDisplacementX [ mm ]
9.12585 × 10-6
42776
-0.00276650
0.00288891
0.00259912
MinDisplacementZ [ mm ]
-6.63621 × 10-4
3492
0.0176434
-0.0190939
0.00437490
MaxVonMisesStress [ MPa ]
21.1947
581345
0.00150383
8.02605 × 10-4
0.00800000
MinVonMisesStress [ MPa ]
1.71520 × 10-6
1022868
-0.00131426
8.97158 × 10-4
0.00900000
MaxPrincipalStressStress [ MPa ]
20.6199
966201
0.00151127
-6.10997 × 10-4
0.00788393
MinPrincipalStressStress [ MPa ]
-7.30087
855376
0.00158890
1.72400 × 10-4
0.00808715

Run time information

Wall time [ hh:mm:ss ]
00:25:15

Static Analysis

Quantity
Value
Node
X-coordinate
Y-coordinate
Z-coordinate
MaxDisplacement [ mm ]
0.00100829
2524
0.0175004
-0.0192273
0.00439092
MinDisplacement [ mm ]
0
1
-0.00160000
0
0.00800000
MaxDisplacementX [ mm ]
6.73066 × 10-4
125
3.68080 × 10-4
-0.0259974
0.00800000
MinDisplacementX [ mm ]
-7.31137 × 10-4
11941
-3.31120 × 10-4
0.0259683
0.00124938
MaxDisplacementY [ mm ]
7.53174 × 10-4
18239
0.0259492
3.47706 × 10-4
0.00121225
MinDisplacementY [ mm ]
-6.71703 × 10-4
84
-0.0259998
9.99770 × 10-5
0.00800000
MaxDisplacementX [ mm ]
6.67225 × 10-5
815
-0.0163165
0.0202428
0.00554026
MinDisplacementZ [ mm ]
-7.45623 × 10-4
2737
0.0151647
-0.0211195
0.00441300
MaxVonMisesStress [ MPa ]
21.4542
581345
0.00150383
8.02605 × 10-4
0.00800000
MinVonMisesStress [ MPa ]
1.46749 × 10-6
323912
-4.41472 × 10-4
0.00152686
0.00900000
MaxPrincipalStressStress [ MPa ]
22.0914
966201
0.00151127
-6.10997 × 10-4
0.00788393
MinPrincipalStressStress [ MPa ]
-8.18151
261948
-7.34799 × 10-4
0.00146004
0.00789486
