General Settings

Fluid-Structure Interaction Performed
yes
Source for FSI
This TCFD Case
Rotates with CFD Frame
rotating
Used CFD Patches
2:blade-rot
Number of Components
1
Thermal Effects Considered
no
Angular Velocity [ rad/s ]
-19.6350

Material Description - 13Cr-4Ni High Alloy Steel

Used for Components
Co1
Density [ kg/m3 ]
7700.00
Type
isotropic
Young Modulus [ GPa ]
200.000
Poisson Ratio [ - ]
0.424000

Solver

Number of Parallel Threads
6
Finite Element Order
2
Nonlinear Governing Equation
no
Eigenmodes for Deformed Solid
no

Mesh Statistics - Component Co1

Meshing Engine
NetGen
Meshing Time [ hh:mm:ss ]
00:00:27
Number of Points
41454
Number of Elements
125549
Number of Surface Faces
78492
Shortest Edge [ mm ]
1.05000 × 10-4
Longest Edge [ mm ]
0.0998840
Minimal Angle Between Edges [ deg ]
0.371409
Maximal Angle Between Edges [ deg ]
153.795
Minimal Angle Between Faces [ deg ]
0.570581
Maximal Angle Between Faces [ deg ]
176.845

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2058
0.0107077 [ m ]
(-1.70469 0.417696 -0.408347)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
246
0.00476152 [ m ]
(-0.380218 -1.74224 -0.244418)
Minimal Displacement X
1189
-0.00463354 [ m ]
(0.751539 1.63557 -0.00320903)
Maximal Displacement Y
708
0.00455498 [ m ]
(1.72879 -0.488297 -0.102723)
Minimal Displacement Y
2198
-0.00485016 [ m ]
(-1.73769 0.273378 -0.381182)
Maximal Displacement Z
1311
3.67800 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Minimal Displacement Z
2058
-0.00959124 [ m ]
(-1.70469 0.417696 -0.408347)
Maximal Displacement Axial
2058
0.00959124 [ m ]
(-1.70469 0.417696 -0.408347)
Minimal Displacement Axial
1311
-3.67800 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Maximal Displacement Radial
2051
0.00136681 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
0.00136681 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
1.52545 × 10-4 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
1202
-0.00468798 [ m ]
(1.01636 1.48118 -0.109813)
Maximal Von Mises Stress
233426
486.717 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
303.870 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2058
0.00935918 [ m ]
(-1.70469 0.417696 -0.408347)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
252
0.00413733 [ m ]
(-0.517035 -1.69973 -0.287868)
Minimal Displacement X
1189
-0.00401679 [ m ]
(0.751539 1.63557 -0.00320903)
Maximal Displacement Y
708
0.00396253 [ m ]
(1.72879 -0.488297 -0.102723)
Minimal Displacement Y
2198
-0.00423216 [ m ]
(-1.73769 0.273378 -0.381182)
Maximal Displacement Z
1311
3.01611 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Minimal Displacement Z
240318
-0.00838612 [ m ]
(-1.70119 0.428974 -0.412215)
Maximal Displacement Axial
240318
0.00838612 [ m ]
(-1.70119 0.428974 -0.412215)
Minimal Displacement Axial
1311
-3.01611 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Maximal Displacement Radial
2051
0.00120459 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
0.00120459 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
79309
1.26719 × 10-4 [ m ]
(0.783062 0.0698529 -0.465997)
Minimal Displacement Tangential
1208
-0.00408474 [ m ]
(1.12883 1.39304 -0.155362)
Maximal Von Mises Stress
233426
419.830 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
266.902 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2058
0.00808152 [ m ]
(-1.70469 0.417696 -0.408347)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
252
0.00354460 [ m ]
(-0.517035 -1.69973 -0.287868)
Minimal Displacement X
1189
-0.00340390 [ m ]
(0.751539 1.63557 -0.00320903)
Maximal Displacement Y
709
0.00337678 [ m ]
(1.722 -0.510991 -0.11052)
Minimal Displacement Y
2198
-0.00364110 [ m ]
(-1.73769 0.273378 -0.381182)
Maximal Displacement Z
1311
2.61396 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Minimal Displacement Z
2057
-0.00724764 [ m ]
(-1.6977 0.440253 -0.416082)
Maximal Displacement Axial
2057
0.00724764 [ m ]
(-1.6977 0.440253 -0.416082)
Minimal Displacement Axial
1311
-2.61396 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Maximal Displacement Radial
2051
0.00104389 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
0.00104389 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
1.09666 × 10-4 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
2185
-0.00349510 [ m ]
(-1.77629 -0.0330924 -0.287997)
Maximal Von Mises Stress
233426
356.962 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
228.385 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
240318
0.00686633 [ m ]
(-1.70119 0.428974 -0.412215)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
252
0.00297394 [ m ]
(-0.517035 -1.69973 -0.287868)
Minimal Displacement X
1577
-0.00282219 [ m ]
(-0.105526 1.75066 -0.416209)
Maximal Displacement Y
709
0.00282076 [ m ]
(1.722 -0.510991 -0.11052)
Minimal Displacement Y
2198
-0.00307681 [ m ]
(-1.73769 0.273378 -0.381182)
Maximal Displacement Z
1311
2.20378 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Minimal Displacement Z
2056
-0.00616680 [ m ]
(-1.69071 0.46281 -0.423817)
Maximal Displacement Axial
2056
0.00616680 [ m ]
(-1.69071 0.46281 -0.423817)
Minimal Displacement Axial
1311
-2.20378 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Maximal Displacement Radial
2051
8.89631 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
8.89631 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
9.29163 × 10-5 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
2191
-0.00294646 [ m ]
(-1.76557 0.109189 -0.331143)
Maximal Von Mises Stress
233426
297.544 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
191.969 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:51

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2056
0.00572776 [ m ]
(-1.69071 0.46281 -0.423817)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
252
0.00243057 [ m ]
(-0.517035 -1.69973 -0.287868)
Minimal Displacement X
223041
-0.00232322 [ m ]
(-0.0936573 1.75083 -0.420097)
Maximal Displacement Y
715
0.00228802 [ m ]
(1.67299 -0.645005 -0.156006)
Minimal Displacement Y
2203
-0.00254792 [ m ]
(-1.70967 0.389119 -0.416616)
Maximal Displacement Z
1311
1.78640 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Minimal Displacement Z
2055
-0.00515469 [ m ]
(-1.68373 0.485367 -0.431551)
Maximal Displacement Axial
2055
0.00515469 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Axial
1311
-1.78640 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Maximal Displacement Radial
2051
7.43461 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
7.43461 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
7.61681 × 10-5 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
2191
-0.00242792 [ m ]
(-1.76557 0.109189 -0.331143)
Maximal Von Mises Stress
233426
240.653 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
158.304 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2055
0.00465020 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
258
0.00191747 [ m ]
(-0.649597 -1.64533 -0.331197)
Minimal Displacement X
1576
-0.00185039 [ m ]
(-0.0817885 1.75099 -0.423985)
Maximal Displacement Y
715
0.00178502 [ m ]
(1.67299 -0.645005 -0.156006)
Minimal Displacement Y
2204
-0.00204747 [ m ]
(-1.70407 0.412268 -0.423702)
Maximal Displacement Z
1311
1.36949 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Minimal Displacement Z
2055
-0.00419532 [ m ]
(-1.68373 0.485367 -0.431551)
Maximal Displacement Axial
2055
0.00419532 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Axial
1311
-1.36949 × 10-4 [ m ]
(0.869607 0.0631054 -0.476386)
Maximal Displacement Radial
2051
6.03538 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
6.03538 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
5.96100 × 10-5 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
2197
-0.00194024 [ m ]
(-1.7429 0.250156 -0.37408)
Maximal Von Mises Stress
233426
186.296 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
126.795 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:49

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2055
0.00413283 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
258
0.00167453 [ m ]
(-0.649597 -1.64533 -0.331197)
Minimal Displacement X
228655
-0.00162359 [ m ]
(-0.0699198 1.75115 -0.427873)
Maximal Displacement Y
721
0.00154678 [ m ]
(1.61233 -0.774572 -0.200245)
Minimal Displacement Y
2204
-0.00180738 [ m ]
(-1.70407 0.412268 -0.423702)
Maximal Displacement Z
219532
1.16596 × 10-4 [ m ]
(0.857447 0.0630494 -0.474043)
Minimal Displacement Z
2055
-0.00373418 [ m ]
(-1.68373 0.485367 -0.431551)
Maximal Displacement Axial
2055
0.00373418 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Axial
219532
-1.16596 × 10-4 [ m ]
(0.857447 0.0630494 -0.474043)
Maximal Displacement Radial
2051
5.35930 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
5.35930 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
5.14463 × 10-5 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
2197
-0.00170713 [ m ]
(-1.7429 0.250156 -0.37408)
Maximal Von Mises Stress
233426
160.073 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
111.974 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2055
0.00363709 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
258
0.00144395 [ m ]
(-0.649597 -1.64533 -0.331197)
Minimal Displacement X
1575
-0.00140345 [ m ]
(-0.058051 1.75131 -0.43176)
Maximal Displacement Y
727
0.00132194 [ m ]
(1.5405 -0.898525 -0.243875)
Minimal Displacement Y
2204
-0.00157731 [ m ]
(-1.70407 0.412268 -0.423702)
Maximal Displacement Z
219532
9.64650 × 10-5 [ m ]
(0.857447 0.0630494 -0.474043)
Minimal Displacement Z
2055
-0.00329225 [ m ]
(-1.68373 0.485367 -0.431551)
Maximal Displacement Axial
2055
0.00329225 [ m ]
(-1.68373 0.485367 -0.431551)
Minimal Displacement Axial
219532
-9.64650 × 10-5 [ m ]
(0.857447 0.0630494 -0.474043)
Maximal Displacement Radial
2051
4.70945 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
4.70945 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
1260
4.33384 × 10-5 [ m ]
(0.795017 0.0696096 -0.469198)
Minimal Displacement Tangential
2197
-0.00148374 [ m ]
(-1.7429 0.250156 -0.37408)
Maximal Von Mises Stress
233426
134.826 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
97.8911 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:49

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2208
0.00316932 [ m ]
(-1.67604 0.503441 -0.451616)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
206192
0.00122210 [ m ]
(-0.745301 -1.59629 -0.363538)
Minimal Displacement X
1575
-0.00119217 [ m ]
(-0.058051 1.75131 -0.43176)
Maximal Displacement Y
739
0.00111556 [ m ]
(1.36528 -1.12503 -0.330683)
Minimal Displacement Y
2204
-0.00135887 [ m ]
(-1.70407 0.412268 -0.423702)
Maximal Displacement Z
147920
7.69151 × 10-5 [ m ]
(0.833127 0.0629375 -0.469358)
Minimal Displacement Z
244365
-0.00287472 [ m ]
(-1.67984 0.496502 -0.435453)
Maximal Displacement Axial
244365
0.00287472 [ m ]
(-1.67984 0.496502 -0.435453)
Minimal Displacement Axial
147920
-7.69151 × 10-5 [ m ]
(0.833127 0.0629375 -0.469358)
Maximal Displacement Radial
2051
4.09234 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
4.09234 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
79309
3.53842 × 10-5 [ m ]
(0.783062 0.0698529 -0.465997)
Minimal Displacement Tangential
239732
-0.00127247 [ m ]
(-1.71808 0.354397 -0.405986)
Maximal Von Mises Stress
233426
110.533 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
84.5852 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38

Run time information

Wall time [ hh:mm:ss ]
00:00:50

Static Analysis

Quantity
Node
Value
Coordinates
Maximal Displacement Magnitude
2208
0.00270439 [ m ]
(-1.67604 0.503441 -0.451616)
Minimal Displacement Magnitude
19
0 [ m ]
(-0.221112 -0.639151 -0.25184)
Maximal Displacement X
264
0.00101097 [ m ]
(-0.777203 -1.57994 -0.374318)
Minimal Displacement X
1575
-9.86562 × 10-4 [ m ]
(-0.058051 1.75131 -0.43176)
Maximal Displacement Y
739
9.28109 × 10-4 [ m ]
(1.36528 -1.12503 -0.330683)
Minimal Displacement Y
2205
-0.00114236 [ m ]
(-1.69725 0.435115 -0.430698)
Maximal Displacement Z
1309
5.77146 × 10-5 [ m ]
(0.820966 0.0628815 -0.467015)
Minimal Displacement Z
2054
-0.00245976 [ m ]
(-1.67595 0.507638 -0.439354)
Maximal Displacement Axial
2054
0.00245976 [ m ]
(-1.67595 0.507638 -0.439354)
Minimal Displacement Axial
1309
-5.77146 × 10-5 [ m ]
(0.820966 0.0628815 -0.467015)
Maximal Displacement Radial
2051
3.47729 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Minimal Displacement Radial
2051
3.47729 × 10-4 [ m ]
(-1.65257 0.573416 -0.462477)
Maximal Displacement Tangential
17897
3.20688 × 10-5 [ m ]
(0.0808372 1.03489 0.427405)
Minimal Displacement Tangential
2204
-0.00106718 [ m ]
(-1.70407 0.412268 -0.423702)
Maximal Von Mises Stress
233426
87.5474 [ MPa ]
(0.806665 -0.32771 -0.122057)
Minimal Von Mises Stress
20
0 [ MPa ]
(-0.203169 -0.650229 -0.239276)
Maximal Principal Stress
205969
71.3688 [ MPa ]
(-0.812122 0.056455 -0.183736)

Frequency Analysis

Mode Nr.
Eigenvalue
Frequency - Real Part [ Hz ]
Frequency - Imaginary Part [ Hz ]
1
257559.
80.7715
0
2
257680.
80.7906
0
3
258366.
80.8981
0

Participation Factor

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
-2.48125
8.05088
10.6751
-1.00504
21.0632
-9.55437
2
10.9728
-2.55210
-4.69197
24.9848
-12.9926
4.20656
3
6.37317
5.20157
15.0220
18.7131
8.65688
-13.4468

Effective Modal Mass

Mode Nr.
Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
1
6.15663
64.8166
113.958
1.01010
443.657
91.2860
2
120.403
6.51322
22.0146
624.239
168.807
17.6951
3
40.6173
27.0563
225.662
350.180
74.9416
180.818
Total
167.177
98.3861
361.634
975.429
975.429
975.429

Total Effective Mass

Translation X
Translation Y
Translation Z
Rotation X
Rotation Y
Rotation Z
3751.89
3751.89
3751.89
2944.38
2944.38
2944.38
