Test Case Name |
tcfdcase0 |
Number of Points [ – ] |
1 |
Machine Type |
propeller |
Rotation Speed [ RPM ] |
8000.00 |
Number of Components [ – ] (topology) |
2 |
Mesh Size [ cells ] (details) |
Domain : 290349
Rotor : 217328
Total : 507677 |
Mesh details [ mm ]:
Component |
Property |
Min |
Max |
Avg |
1 |
cellOpenness |
N/A |
3.71963 × 10-16
|
N/A |
1 |
cellVolume |
0.880228 |
28027.5 |
N/A |
1 |
faceArea |
0.109688 |
1563.63 |
N/A |
1 |
aspectRatio |
N/A |
5.86383 |
N/A |
1 |
nonOrthogonality |
N/A |
48.2718 |
6.47326 |
1 |
skewness |
N/A |
3.04324 |
N/A |
1 |
edgeLength |
N/A |
N/A |
N/A |
1 |
concaveAngle |
N/A |
41.3390 |
N/A |
1 |
faceFlatness |
0.818818 |
N/A |
0.999320 |
1 |
cellDeterminant |
0.139372 |
N/A |
8.80636 |
1 |
faceInterpolationWeight |
0.159300 |
N/A |
0.486330 |
1 |
faceVolumeRatio |
0.111355 |
0.928799 |
N/A |
1 |
Warnings: |
48 faces with low quality or negative volume decomposition tets
66 faces with concave angles
5767 concave cells
|
2 |
cellOpenness |
N/A |
4.25590 × 10-16
|
N/A |
2 |
cellVolume |
0.00157652 |
11.2665 |
N/A |
2 |
faceArea |
2.45466 × 10-4
|
6.77503 |
N/A |
2 |
aspectRatio |
N/A |
5.82517 |
N/A |
2 |
nonOrthogonality |
N/A |
62.9393 |
9.61884 |
2 |
skewness |
N/A |
7.48044 |
N/A |
2 |
edgeLength |
0 |
3.08717 |
N/A |
2 |
concaveAngle |
N/A |
79.9304 |
N/A |
2 |
faceFlatness |
0.783915 |
N/A |
0.999294 |
2 |
cellDeterminant |
0.176047 |
N/A |
15.1865 |
2 |
faceInterpolationWeight |
0.122328 |
N/A |
0.470437 |
2 |
faceVolumeRatio |
0.0287440 |
0.847644 |
N/A |
2 |
Warnings: |
2 skew faces
451 faces with low quality or negative volume decomposition tets
10 points on short edges
1199 faces with concave angles
1 warped faces
11086 concave cells
|
|
Average y+ at walls [ – ] (details) |
y+ details:
Point |
Patch |
Min |
Max |
Avg |
1 |
Rotor_propeller-SS_wall |
0.00214195 |
32.8387 |
1.72364 |
1 |
Rotor_propeller-hub_wall |
4.31221 × 10-4
|
0.290373 |
0.0772831 |
1 |
Rotor_propeller-PS_wall |
0.00171162 |
3.38489 |
0.454505 |
1 |
Rotor_propeller-LETE_wall |
1.29417 × 10-4
|
12.2377 |
0.835784 |
|
Wall-clock time [ hh:mm:ss ] |
00:13:03 |
Parallel Processors [ – ] |
6 |
Fluid Name |
air |
Physical Model |
incompressible |
Equation of state |
|
Numerical order |
first |
Turbulence model |
kOmegaSST |
