eveningTest CFD Simulation Resuls

Simulation Stats

Test Case Name

eveningTest

Number of Points [ – ]

10

Machine Type

fan

Rotation Speed [ RPM ]

1800.00

Number of Components [ – ]

(topology)

4

Mesh Size [ cells ]

(details)

inflow : 548

rotor : 4510

volute : 1307

outflow : 880

Total : 7245

Mesh details [ mm ]:

Component	Property	Min	Max	Avg
1	cellOpenness	N/A	1.80288 × 10^-16	N/A
1	cellVolume	30.4723	84.9632	N/A
1	faceArea	4.50018	42.4776	N/A
1	aspectRatio	N/A	5.33397	N/A
1	nonOrthogonality	N/A	32.1432	8.12137
1	skewness	N/A	0.312262	N/A
1	edgeLength	N/A	N/A	N/A
1	concaveAngle	N/A	N/A	N/A
1	faceFlatness	1.00000	N/A	1.00000
1	cellDeterminant	0	N/A	4.39390 × 10^-35
1	faceInterpolationWeight	0.340285	N/A	0.463935
1	faceVolumeRatio	0.515806	0.872343	N/A
1	Warnings:	548 under-determined cells
2	cellOpenness	N/A	2.09901 × 10^-16	N/A
2	cellVolume	0.737859	66.2244	N/A
2	faceArea	0.108968	42.9778	N/A
2	aspectRatio	N/A	41.0796	N/A
2	nonOrthogonality	N/A	34.9651	9.99134
2	skewness	N/A	0.420690	N/A
2	edgeLength	N/A	N/A	N/A
2	concaveAngle	N/A	N/A	N/A
2	faceFlatness	1.00000	N/A	1.00000
2	cellDeterminant	0	N/A	1.23242 × 10^-35
2	faceInterpolationWeight	0.186108	N/A	0.420993
2	faceVolumeRatio	0.228663	0.745721	N/A
2	Warnings:	4510 under-determined cells
3	cellOpenness	N/A	2.01308 × 10^-16	N/A
3	cellVolume	6.91739	842.852	N/A
3	faceArea	1.02157	128.259	N/A
3	aspectRatio	N/A	12.7867	N/A
3	nonOrthogonality	N/A	32.6687	9.65405
3	skewness	N/A	0.375026	N/A
3	edgeLength	N/A	N/A	N/A
3	concaveAngle	N/A	N/A	N/A
3	faceFlatness	1.00000	N/A	1.00000
3	cellDeterminant	0	N/A	1.60410 × 10^-34
3	faceInterpolationWeight	0.233563	N/A	0.437964
3	faceVolumeRatio	0.304738	0.792691	N/A
3	Warnings:	1307 under-determined cells
4	cellOpenness	N/A	2.05061 × 10^-16	N/A
4	cellVolume	115.708	1863.55	N/A
4	faceArea	17.0879	275.211	N/A
4	aspectRatio	N/A	6.72205	N/A
4	nonOrthogonality	N/A	2.94739	0.628992
4	skewness	N/A	0.128718	N/A
4	edgeLength	N/A	N/A	N/A
4	concaveAngle	N/A	N/A	N/A
4	faceFlatness	1.00000	N/A	1.00000
4	cellDeterminant	0	N/A	4.94519 × 10^-38
4	faceInterpolationWeight	0.326697	N/A	0.469620
4	faceVolumeRatio	0.485215	0.892660	N/A
4	Warnings:	880 under-determined cells

Average y+ at walls [ – ]
(details)

178.173

Wall-clock time [ hh:mm:ss ]

00:02:28

Parallel Processors [ – ]

6

Fluid Name

air

Compressibility

incompressible

Fan Characteristic

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow number [ – ]	Compression number [ – ]
1	0.0713368	2.05107
2	0.0636438	2.09407
3	0.0574112	2.09843
4	0.0523851	2.08173
5	0.0481520	2.04637
6	0.0445257	1.99909
7	0.0412872	1.93639
8	0.0403908	1.90035
9	0.0390666	1.83929
10	0.0369361	1.71401

Efficiency

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Efficiency [ – ]
1	0.0144981	0.501105
2	0.0129347	0.542581
3	0.0116680	0.571918
4	0.0106465	0.592417
5	0.00978617	0.605550
6	0.00904918	0.612266
7	0.00839100	0.612263
8	0.00820882	0.605689
9	0.00793971	0.592522
10	0.00750670	0.562304

Torque

Point Nr.	Torque [ N.m ]
1	0.0328697
2	0.0276487
3	0.0237102
4	0.0207193
5	0.0183154
6	0.0163634
7	0.0146976
8	0.0142642
9	0.0136503
10	0.0126760

Axial Force

Point Nr.	Axial Force [ N ]
1	7.22554 × 10^-17
2	7.22873 × 10^-17
3	7.23105 × 10^-17
4	7.23294 × 10^-17
5	7.23436 × 10^-17
6	7.23561 × 10^-17
7	7.23671 × 10^-17
8	7.23696 × 10^-17
9	7.23720 × 10^-17
10	7.23743 × 10^-17

Total Pressure Difference

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Total Pressure Difference [ Pa ]
1	0.0144981	214.255
2	0.0129347	218.747
3	0.0116680	219.203
4	0.0106465	217.459
5	0.00978617	213.765
6	0.00904918	208.826
7	0.00839100	202.276
8	0.00820882	198.512
9	0.00793971	192.133
10	0.00750670	179.047

Total Pressure per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Total Pressure [ Pa ]
1	inflow-in	0.0144981	101325.
1	inflow-to-rotor	0.0144981	101321.
1	rotor-from-inflow	0.0144981	101321.
1	rotor-to-volute	0.0144981	101580.
1	volute-from-rotor	0.0144981	101580.
1	volute-to-outflow	0.0144981	101552.
1	outflow-from-volute	0.0144981	101552.
1	outflow-out	0.0144981	101539.
2	inflow-in	0.0129347	101325.
2	inflow-to-rotor	0.0129347	101322.
2	rotor-from-inflow	0.0129347	101322.
2	rotor-to-volute	0.0129347	101578.
2	volute-from-rotor	0.0129347	101578.
2	volute-to-outflow	0.0129347	101554.
2	outflow-from-volute	0.0129347	101554.
2	outflow-out	0.0129347	101544.
3	inflow-in	0.0116680	101325.
3	inflow-to-rotor	0.0116680	101322.
3	rotor-from-inflow	0.0116680	101322.
3	rotor-to-volute	0.0116680	101574.
3	volute-from-rotor	0.0116680	101574.
3	volute-to-outflow	0.0116680	101552.
3	outflow-from-volute	0.0116680	101552.
3	outflow-out	0.0116680	101544.
4	inflow-in	0.0106465	101325.
4	inflow-to-rotor	0.0106465	101323.
4	rotor-from-inflow	0.0106465	101323.
4	rotor-to-volute	0.0106465	101568.
4	volute-from-rotor	0.0106465	101568.
4	volute-to-outflow	0.0106465	101549.
4	outflow-from-volute	0.0106465	101549.
4	outflow-out	0.0106465	101542.
5	inflow-in	0.00978617	101325.
5	inflow-to-rotor	0.00978617	101323.
5	rotor-from-inflow	0.00978617	101323.
5	rotor-to-volute	0.00978617	101561.
5	volute-from-rotor	0.00978617	101561.
5	volute-to-outflow	0.00978617	101544.
5	outflow-from-volute	0.00978617	101544.
5	outflow-out	0.00978617	101539.
6	inflow-in	0.00904918	101325.
6	inflow-to-rotor	0.00904918	101324.
6	rotor-from-inflow	0.00904918	101324.
6	rotor-to-volute	0.00904918	101554.
6	volute-from-rotor	0.00904918	101554.
6	volute-to-outflow	0.00904918	101539.
6	outflow-from-volute	0.00904918	101539.
6	outflow-out	0.00904918	101534.
7	inflow-in	0.00839100	101325.
7	inflow-to-rotor	0.00839100	101324.
7	rotor-from-inflow	0.00839100	101324.
7	rotor-to-volute	0.00839100	101546.
7	volute-from-rotor	0.00839100	101546.
7	volute-to-outflow	0.00839100	101533.
7	outflow-from-volute	0.00839100	101533.
7	outflow-out	0.00839100	101527.
8	inflow-in	0.00820882	101325.
8	inflow-to-rotor	0.00820882	101324.
8	rotor-from-inflow	0.00820882	101324.
8	rotor-to-volute	0.00820882	101544.
8	volute-from-rotor	0.00820882	101544.
8	volute-to-outflow	0.00820882	101531.
8	outflow-from-volute	0.00820882	101531.
8	outflow-out	0.00820883	101524.
9	inflow-in	0.00793971	101325.
9	inflow-to-rotor	0.00793971	101324.
9	rotor-from-inflow	0.00793971	101324.
9	rotor-to-volute	0.00793971	101541.
9	volute-from-rotor	0.00793971	101541.
9	volute-to-outflow	0.00793971	101525.
9	outflow-from-volute	0.00793971	101525.
9	outflow-out	0.00793970	101517.
10	inflow-in	0.00750670	101325.
10	inflow-to-rotor	0.00750671	101324.
10	rotor-from-inflow	0.00750671	101324.
10	rotor-to-volute	0.00750671	101535.
10	volute-from-rotor	0.00750671	101535.
10	volute-to-outflow	0.00750670	101516.
10	outflow-from-volute	0.00750670	101516.
10	outflow-out	0.00750667	101504.

Velocity Magnitude per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Velocity Magnitude [ m/s ]
1	inflow-in	0.0144981	12.2089
1	inflow-to-rotor	0.0144981	9.08597
1	rotor-from-inflow	0.0144981	9.08597
1	rotor-to-volute	0.0144981	25.2180
1	volute-from-rotor	0.0144981	25.2182
1	volute-to-outflow	0.0144981	20.7640
1	outflow-from-volute	0.0144981	20.7640
1	outflow-out	0.0144981	15.2634
2	inflow-in	0.0129347	10.8532
2	inflow-to-rotor	0.0129347	8.07566
2	rotor-from-inflow	0.0129347	8.07566
2	rotor-to-volute	0.0129347	23.6166
2	volute-from-rotor	0.0129347	23.6168
2	volute-to-outflow	0.0129347	18.4704
2	outflow-from-volute	0.0129347	18.4704
2	outflow-out	0.0129347	13.4255
3	inflow-in	0.0116680	9.74233
3	inflow-to-rotor	0.0116680	7.25024
3	rotor-from-inflow	0.0116680	7.25025
3	rotor-to-volute	0.0116680	22.3274
3	volute-from-rotor	0.0116680	22.3277
3	volute-to-outflow	0.0116680	16.6031
3	outflow-from-volute	0.0116680	16.6031
3	outflow-out	0.0116680	12.0471
4	inflow-in	0.0106465	8.83277
4	inflow-to-rotor	0.0106465	6.57673
4	rotor-from-inflow	0.0106465	6.57673
4	rotor-to-volute	0.0106465	21.1931
4	volute-from-rotor	0.0106465	21.1933
4	volute-to-outflow	0.0106465	15.0858
4	outflow-from-volute	0.0106465	15.0858
4	outflow-out	0.0106465	10.9651
5	inflow-in	0.00978617	8.05474
5	inflow-to-rotor	0.00978617	5.99892
5	rotor-from-inflow	0.00978617	5.99892
5	rotor-to-volute	0.00978617	20.1927
5	volute-from-rotor	0.00978617	20.1930
5	volute-to-outflow	0.00978617	13.8493
5	outflow-from-volute	0.00978617	13.8493
5	outflow-out	0.00978617	10.0704
6	inflow-in	0.00904918	7.38362
6	inflow-to-rotor	0.00904918	5.50472
6	rotor-from-inflow	0.00904918	5.50471
6	rotor-to-volute	0.00904918	19.3260
6	volute-from-rotor	0.00904918	19.3261
6	volute-to-outflow	0.00904918	12.8979
6	outflow-from-volute	0.00904918	12.8979
6	outflow-out	0.00904918	9.31321
7	inflow-in	0.00839100	6.77422
7	inflow-to-rotor	0.00839100	5.05741
7	rotor-from-inflow	0.00839100	5.05740
7	rotor-to-volute	0.00839100	18.5034
7	volute-from-rotor	0.00839100	18.5034
7	volute-to-outflow	0.00839100	12.2677
7	outflow-from-volute	0.00839100	12.2677
7	outflow-out	0.00839100	8.64311
8	inflow-in	0.00820882	6.61192
8	inflow-to-rotor	0.00820882	4.94424
8	rotor-from-inflow	0.00820882	4.94422
8	rotor-to-volute	0.00820882	18.2698
8	volute-from-rotor	0.00820882	18.2699
8	volute-to-outflow	0.00820882	12.4075
8	outflow-from-volute	0.00820882	12.4075
8	outflow-out	0.00820883	8.46773
9	inflow-in	0.00793971	6.36908
9	inflow-to-rotor	0.00793971	4.78020
9	rotor-from-inflow	0.00793971	4.78017
9	rotor-to-volute	0.00793971	17.9890
9	volute-from-rotor	0.00793971	17.9889
9	volute-to-outflow	0.00793971	12.6141
9	outflow-from-volute	0.00793971	12.6141
9	outflow-out	0.00793970	8.23709
10	inflow-in	0.00750670	5.97100
10	inflow-to-rotor	0.00750671	4.51620
10	rotor-from-inflow	0.00750671	4.51616
10	rotor-to-volute	0.00750671	17.4364
10	volute-from-rotor	0.00750671	17.4362
10	volute-to-outflow	0.00750670	12.8408
10	outflow-from-volute	0.00750670	12.8408
10	outflow-out	0.00750667	7.86624

Circumferential and Meridional Angle

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Circumferential Angle [ deg ]	Meridional Angle [ deg ]
1	inflow-in	0.0144981	90.0001	90.0000
1	inflow-to-rotor	0.0144981	89.6941	90.0000
1	rotor-from-inflow	0.0144981	138.469*	90.0000*
1	rotor-to-volute	0.0144981	41.4871*	89.6807*
1	volute-from-rotor	0.0144981	14.3620	89.6814
1	volute-to-outflow	0.0144981	-0.738899	88.0815
1	outflow-from-volute	0.0144981	-0.738899	88.0815
1	outflow-out	0.0144981	-3.79668 × 10^-9	90.0000
2	inflow-in	0.0129347	90.0001	90.0000
2	inflow-to-rotor	0.0129347	89.6720	90.0000
2	rotor-from-inflow	0.0129347	141.570*	90.0000*
2	rotor-to-volute	0.0129347	43.0727*	89.4104*
2	volute-from-rotor	0.0129347	13.5567	89.4111
2	volute-to-outflow	0.0129347	0.747595	88.0461
2	outflow-from-volute	0.0129347	0.747595	88.0461
2	outflow-out	0.0129347	-1.02004 × 10^-9	90.0000
3	inflow-in	0.0116680	90.0001	90.0000
3	inflow-to-rotor	0.0116680	89.6448	90.0000
3	rotor-from-inflow	0.0116680	144.356*	90.0000*
3	rotor-to-volute	0.0116680	44.8007*	89.2478*
3	volute-from-rotor	0.0116680	12.8784	89.2487
3	volute-to-outflow	0.0116680	0.864850	88.0102
3	outflow-from-volute	0.0116680	0.864850	88.0102
3	outflow-out	0.0116680	5.99385 × 10^-9	90.0000
4	inflow-in	0.0106465	90.0001	90.0000
4	inflow-to-rotor	0.0106465	89.6085	90.0000
4	rotor-from-inflow	0.0106465	146.810*	90.0000*
4	rotor-to-volute	0.0106465	46.2805*	88.5364*
4	volute-from-rotor	0.0106465	12.2555	88.5371
4	volute-to-outflow	0.0106465	1.05045	88.1086
4	outflow-from-volute	0.0106465	1.05045	88.1086
4	outflow-out	0.0106465	-6.36757 × 10^-9	90.0000
5	inflow-in	0.00978617	90.0001	90.0000
5	inflow-to-rotor	0.00978617	89.5759	90.0000
5	rotor-from-inflow	0.00978617	149.047*	90.0000*
5	rotor-to-volute	0.00978617	48.0748*	87.8001*
5	volute-from-rotor	0.00978617	11.7042	87.8012
5	volute-to-outflow	0.00978617	1.21594	87.9802
5	outflow-from-volute	0.00978617	1.21594	87.9802
5	outflow-out	0.00978617	-2.12005 × 10^-8	90.0000
6	inflow-in	0.00904918	90.0001	90.0000
6	inflow-to-rotor	0.00904918	89.5295	90.0000
6	rotor-from-inflow	0.00904918	151.071*	90.0000*
6	rotor-to-volute	0.00904918	49.9580*	87.0633*
6	volute-from-rotor	0.00904918	11.2138	87.0636
6	volute-to-outflow	0.00904918	1.16378	87.9359
6	outflow-from-volute	0.00904918	1.16378	87.9359
6	outflow-out	0.00904918	-5.36417 × 10^-9	90.0000
7	inflow-in	0.00839100	90.0002	90.0000
7	inflow-to-rotor	0.00839100	89.4702	90.0000
7	rotor-from-inflow	0.00839100	152.984*	90.0000*
7	rotor-to-volute	0.00839100	51.7216*	86.2138*
7	volute-from-rotor	0.00839100	10.7642	86.2141
7	volute-to-outflow	0.00839100	0.834559	87.8189
7	outflow-from-volute	0.00839100	0.834559	87.8189
7	outflow-out	0.00839100	-5.04235 × 10^-9	90.0000
8	inflow-in	0.00820882	90.0002	90.0000
8	inflow-to-rotor	0.00820882	89.4232	90.0000
8	rotor-from-inflow	0.00820882	153.489*	90.0000*
8	rotor-to-volute	0.00820882	51.9531*	85.7474*
8	volute-from-rotor	0.00820882	10.6393	85.7470
8	volute-to-outflow	0.00820882	0.369633	87.6146
8	outflow-from-volute	0.00820882	0.369633	87.6146
8	outflow-out	0.00820883	-4.97560 × 10^-10	90.0000
9	inflow-in	0.00793971	90.0002	90.0000
9	inflow-to-rotor	0.00793971	89.3217	90.0000
9	rotor-from-inflow	0.00793971	154.233*	90.0000*
9	rotor-to-volute	0.00793971	53.0511*	85.6883*
9	volute-from-rotor	0.00793971	10.3973	85.6872
9	volute-to-outflow	0.00793971	1.03470	87.0017
9	outflow-from-volute	0.00793971	1.03470	87.0017
9	outflow-out	0.00793970	4.09220 × 10^-9	90.0000
10	inflow-in	0.00750670	90.0002	90.0000
10	inflow-to-rotor	0.00750671	89.1052	90.0000
10	rotor-from-inflow	0.00750671	155.438*	90.0000*
10	rotor-to-volute	0.00750671	54.6382*	84.9698*
10	volute-from-rotor	0.00750671	9.85051	84.9680
10	volute-to-outflow	0.00750670	1.64785	85.2388
10	outflow-from-volute	0.00750670	1.64785	85.2388
10	outflow-out	0.00750667	-5.80541 × 10^-9	90.0000

(*) Calculated from the relative velocity.

Simulation Stats

Test Case Name

eveningTest

Number of Points [ – ]

10

Machine Type

fan

Rotation Speed [ RPM ]

2000.00

Number of Components [ – ]

(topology)

4

Mesh Size [ cells ]

(details)

inflow : 548

rotor : 4510

volute : 1307

outflow : 880

Total : 7245

Mesh details [ mm ]:

Component	Property	Min	Max	Avg
1	cellOpenness	N/A	1.80288 × 10^-16	N/A
1	cellVolume	30.4723	84.9632	N/A
1	faceArea	4.50018	42.4776	N/A
1	aspectRatio	N/A	5.33397	N/A
1	nonOrthogonality	N/A	32.1432	8.12137
1	skewness	N/A	0.312262	N/A
1	edgeLength	N/A	N/A	N/A
1	concaveAngle	N/A	N/A	N/A
1	faceFlatness	1.00000	N/A	1.00000
1	cellDeterminant	0	N/A	4.39390 × 10^-35
1	faceInterpolationWeight	0.340285	N/A	0.463935
1	faceVolumeRatio	0.515806	0.872343	N/A
1	Warnings:	548 under-determined cells
2	cellOpenness	N/A	2.09901 × 10^-16	N/A
2	cellVolume	0.737859	66.2244	N/A
2	faceArea	0.108968	42.9778	N/A
2	aspectRatio	N/A	41.0796	N/A
2	nonOrthogonality	N/A	34.9651	9.99134
2	skewness	N/A	0.420690	N/A
2	edgeLength	N/A	N/A	N/A
2	concaveAngle	N/A	N/A	N/A
2	faceFlatness	1.00000	N/A	1.00000
2	cellDeterminant	0	N/A	1.23242 × 10^-35
2	faceInterpolationWeight	0.186108	N/A	0.420993
2	faceVolumeRatio	0.228663	0.745721	N/A
2	Warnings:	4510 under-determined cells
3	cellOpenness	N/A	2.01308 × 10^-16	N/A
3	cellVolume	6.91739	842.852	N/A
3	faceArea	1.02157	128.259	N/A
3	aspectRatio	N/A	12.7867	N/A
3	nonOrthogonality	N/A	32.6687	9.65405
3	skewness	N/A	0.375026	N/A
3	edgeLength	N/A	N/A	N/A
3	concaveAngle	N/A	N/A	N/A
3	faceFlatness	1.00000	N/A	1.00000
3	cellDeterminant	0	N/A	1.60410 × 10^-34
3	faceInterpolationWeight	0.233563	N/A	0.437964
3	faceVolumeRatio	0.304738	0.792691	N/A
3	Warnings:	1307 under-determined cells
4	cellOpenness	N/A	2.05061 × 10^-16	N/A
4	cellVolume	115.708	1863.55	N/A
4	faceArea	17.0879	275.211	N/A
4	aspectRatio	N/A	6.72205	N/A
4	nonOrthogonality	N/A	2.94739	0.628992
4	skewness	N/A	0.128718	N/A
4	edgeLength	N/A	N/A	N/A
4	concaveAngle	N/A	N/A	N/A
4	faceFlatness	1.00000	N/A	1.00000
4	cellDeterminant	0	N/A	4.94519 × 10^-38
4	faceInterpolationWeight	0.326697	N/A	0.469620
4	faceVolumeRatio	0.485215	0.892660	N/A
4	Warnings:	880 under-determined cells

Average y+ at walls [ – ]
(details)

197.193

Wall-clock time [ hh:mm:ss ]

00:02:27

Parallel Processors [ – ]

6

Fluid Name

air

Compressibility

incompressible

Fan Characteristic

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow number [ – ]	Compression number [ – ]
1	0.0713724	2.05330
2	0.0636688	2.09566
3	0.0574336	2.09995
4	0.0524034	2.08306
5	0.0481684	2.04761
6	0.0445377	1.99980
7	0.0413018	1.93751
8	0.0404300	1.90245
9	0.0391357	1.84289
10	0.0369706	1.72660

Efficiency

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Efficiency [ – ]
1	0.0161171	0.501458
2	0.0143775	0.542792
3	0.0129695	0.572140
4	0.0118336	0.592626
5	0.0108772	0.605769
6	0.0100573	0.612322
7	0.00932663	0.612505
8	0.00912976	0.606027
9	0.00883750	0.593704
10	0.00834859	0.565936

Torque

Point Nr.	Torque [ N.m ]
1	0.0406110
2	0.0341557
3	0.0292886
4	0.0255917
5	0.0226214
6	0.0202095
7	0.0181523
8	0.0176343
9	0.0168790
10	0.0156755

Axial Force

Point Nr.	Axial Force [ N ]
1	7.22183 × 10^-17
2	7.22575 × 10^-17
3	7.22864 × 10^-17
4	7.23097 × 10^-17
5	7.23273 × 10^-17
6	7.23427 × 10^-17
7	7.23563 × 10^-17
8	7.23594 × 10^-17
9	7.23622 × 10^-17
10	7.23652 × 10^-17

Total Pressure Difference

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Total Pressure Difference [ Pa ]
1	0.0161171	264.801
2	0.0143775	270.264
3	0.0129695	270.817
4	0.0118336	268.639
5	0.0108772	264.067
6	0.0100573	257.902
7	0.00932663	249.868
8	0.00912976	245.346
9	0.00883750	237.665
10	0.00834859	222.669

Total Pressure per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Total Pressure [ Pa ]
1	inflow-in	0.0161171	101325.
1	inflow-to-rotor	0.0161171	101320.
1	rotor-from-inflow	0.0161171	101320.
1	rotor-to-volute	0.0161171	101640.
1	volute-from-rotor	0.0161171	101640.
1	volute-to-outflow	0.0161171	101605.
1	outflow-from-volute	0.0161171	101605.
1	outflow-out	0.0161171	101590.
2	inflow-in	0.0143775	101325.
2	inflow-to-rotor	0.0143775	101321.
2	rotor-from-inflow	0.0143775	101321.
2	rotor-to-volute	0.0143775	101637.
2	volute-from-rotor	0.0143775	101637.
2	volute-to-outflow	0.0143775	101608.
2	outflow-from-volute	0.0143775	101608.
2	outflow-out	0.0143775	101595.
3	inflow-in	0.0129695	101325.
3	inflow-to-rotor	0.0129695	101322.
3	rotor-from-inflow	0.0129695	101322.
3	rotor-to-volute	0.0129695	101632.
3	volute-from-rotor	0.0129695	101632.
3	volute-to-outflow	0.0129695	101606.
3	outflow-from-volute	0.0129695	101606.
3	outflow-out	0.0129695	101596.
4	inflow-in	0.0118336	101325.
4	inflow-to-rotor	0.0118336	101322.
4	rotor-from-inflow	0.0118336	101322.
4	rotor-to-volute	0.0118336	101625.
4	volute-from-rotor	0.0118336	101625.
4	volute-to-outflow	0.0118336	101602.
4	outflow-from-volute	0.0118336	101602.
4	outflow-out	0.0118336	101594.
5	inflow-in	0.0108772	101325.
5	inflow-to-rotor	0.0108772	101323.
5	rotor-from-inflow	0.0108772	101323.
5	rotor-to-volute	0.0108772	101616.
5	volute-from-rotor	0.0108772	101616.
5	volute-to-outflow	0.0108772	101596.
5	outflow-from-volute	0.0108772	101596.
5	outflow-out	0.0108772	101589.
6	inflow-in	0.0100573	101325.
6	inflow-to-rotor	0.0100573	101323.
6	rotor-from-inflow	0.0100573	101323.
6	rotor-to-volute	0.0100573	101607.
6	volute-from-rotor	0.0100573	101607.
6	volute-to-outflow	0.0100573	101590.
6	outflow-from-volute	0.0100573	101590.
6	outflow-out	0.0100573	101583.
7	inflow-in	0.00932663	101325.
7	inflow-to-rotor	0.00932663	101323.
7	rotor-from-inflow	0.00932663	101323.
7	rotor-to-volute	0.00932663	101598.
7	volute-from-rotor	0.00932663	101598.
7	volute-to-outflow	0.00932663	101582.
7	outflow-from-volute	0.00932663	101582.
7	outflow-out	0.00932663	101575.
8	inflow-in	0.00912976	101325.
8	inflow-to-rotor	0.00912976	101324.
8	rotor-from-inflow	0.00912976	101324.
8	rotor-to-volute	0.00912976	101595.
8	volute-from-rotor	0.00912976	101595.
8	volute-to-outflow	0.00912976	101579.
8	outflow-from-volute	0.00912976	101579.
8	outflow-out	0.00912977	101570.
9	inflow-in	0.00883750	101325.
9	inflow-to-rotor	0.00883750	101324.
9	rotor-from-inflow	0.00883750	101324.
9	rotor-to-volute	0.00883750	101592.
9	volute-from-rotor	0.00883750	101592.
9	volute-to-outflow	0.00883750	101573.
9	outflow-from-volute	0.00883750	101573.
9	outflow-out	0.00883751	101563.
10	inflow-in	0.00834859	101325.
10	inflow-to-rotor	0.00834859	101324.
10	rotor-from-inflow	0.00834859	101324.
10	rotor-to-volute	0.00834860	101585.
10	volute-from-rotor	0.00834860	101585.
10	volute-to-outflow	0.00834859	101561.
10	outflow-from-volute	0.00834859	101561.
10	outflow-out	0.00834846	101548.

Velocity Magnitude per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Velocity Magnitude [ m/s ]
1	inflow-in	0.0161171	13.5716
1	inflow-to-rotor	0.0161171	10.1000
1	rotor-from-inflow	0.0161171	10.1000
1	rotor-to-volute	0.0161171	28.0275
1	volute-from-rotor	0.0161171	28.0277
1	volute-to-outflow	0.0161171	23.0833
1	outflow-from-volute	0.0161171	23.0833
1	outflow-out	0.0161171	16.9685
2	inflow-in	0.0143775	12.0638
2	inflow-to-rotor	0.0143775	8.97636
2	rotor-from-inflow	0.0143775	8.97636
2	rotor-to-volute	0.0143775	26.2472
2	volute-from-rotor	0.0143775	26.2474
2	volute-to-outflow	0.0143775	20.5299
2	outflow-from-volute	0.0143775	20.5299
2	outflow-out	0.0143775	14.9231
3	inflow-in	0.0129695	10.8283
3	inflow-to-rotor	0.0129695	8.05833
3	rotor-from-inflow	0.0129695	8.05833
3	rotor-to-volute	0.0129695	24.8127
3	volute-from-rotor	0.0129695	24.8131
3	volute-to-outflow	0.0129695	18.4540
3	outflow-from-volute	0.0129695	18.4540
3	outflow-out	0.0129695	13.3906
4	inflow-in	0.0118336	9.81636
4	inflow-to-rotor	0.0118336	7.30895
4	rotor-from-inflow	0.0118336	7.30895
4	rotor-to-volute	0.0118336	23.5505
4	volute-from-rotor	0.0118336	23.5508
4	volute-to-outflow	0.0118336	16.7672
4	outflow-from-volute	0.0118336	16.7672
4	outflow-out	0.0118336	12.1875
5	inflow-in	0.0108772	8.95114
5	inflow-to-rotor	0.0108772	6.66627
5	rotor-from-inflow	0.0108772	6.66627
5	rotor-to-volute	0.0108772	22.4377
5	volute-from-rotor	0.0108772	22.4381
5	volute-to-outflow	0.0108772	15.3920
5	outflow-from-volute	0.0108772	15.3920
5	outflow-out	0.0108772	11.1929
6	inflow-in	0.0100573	8.20493
6	inflow-to-rotor	0.0100573	6.11691
6	rotor-from-inflow	0.0100573	6.11691
6	rotor-to-volute	0.0100573	21.4727
6	volute-from-rotor	0.0100573	21.4729
6	volute-to-outflow	0.0100573	14.3327
6	outflow-from-volute	0.0100573	14.3327
6	outflow-out	0.0100573	10.3500
7	inflow-in	0.00932663	7.52773
7	inflow-to-rotor	0.00932663	5.61958
7	rotor-from-inflow	0.00932663	5.61956
7	rotor-to-volute	0.00932663	20.5591
7	volute-from-rotor	0.00932663	20.5592
7	volute-to-outflow	0.00932663	13.6315
7	outflow-from-volute	0.00932663	13.6315
7	outflow-out	0.00932663	9.60633
8	inflow-in	0.00912976	7.35341
8	inflow-to-rotor	0.00912976	5.49859
8	rotor-from-inflow	0.00912976	5.49858
8	rotor-to-volute	0.00912976	20.3000
8	volute-from-rotor	0.00912976	20.3000
8	volute-to-outflow	0.00912976	13.7660
8	outflow-from-volute	0.00912976	13.7660
8	outflow-out	0.00912977	9.41351
9	inflow-in	0.00883750	7.08608
9	inflow-to-rotor	0.00883750	5.31399
9	rotor-from-inflow	0.00883750	5.31396
9	rotor-to-volute	0.00883750	20.0287
9	volute-from-rotor	0.00883750	20.0285
9	volute-to-outflow	0.00883750	14.0061
9	outflow-from-volute	0.00883750	14.0061
9	outflow-out	0.00883751	9.16250
10	inflow-in	0.00834859	6.64489
10	inflow-to-rotor	0.00834859	5.02651
10	rotor-from-inflow	0.00834859	5.02647
10	rotor-to-volute	0.00834860	19.3777
10	volute-from-rotor	0.00834860	19.3774
10	volute-to-outflow	0.00834859	14.2416
10	outflow-from-volute	0.00834859	14.2416
10	outflow-out	0.00834846	8.77714

Circumferential and Meridional Angle

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Circumferential Angle [ deg ]	Meridional Angle [ deg ]
1	inflow-in	0.0161171	90.0001	90.0000
1	inflow-to-rotor	0.0161171	89.6948	90.0000
1	rotor-from-inflow	0.0161171	138.458*	90.0000*
1	rotor-to-volute	0.0161171	41.4896*	89.6834*
1	volute-from-rotor	0.0161171	14.3643	89.6841
1	volute-to-outflow	0.0161171	-0.739044	88.0804
1	outflow-from-volute	0.0161171	-0.739044	88.0804
1	outflow-out	0.0161171	-5.63848 × 10^-9	90.0000
2	inflow-in	0.0143775	90.0001	90.0000
2	inflow-to-rotor	0.0143775	89.6724	90.0000
2	rotor-from-inflow	0.0143775	141.560*	90.0000*
2	rotor-to-volute	0.0143775	43.0628*	89.4141*
2	volute-from-rotor	0.0143775	13.5586	89.4148
2	volute-to-outflow	0.0143775	0.749466	88.0450
2	outflow-from-volute	0.0143775	0.749466	88.0450
2	outflow-out	0.0143775	2.48335 × 10^-9	90.0000
3	inflow-in	0.0129695	90.0001	90.0000
3	inflow-to-rotor	0.0129695	89.6454	90.0000
3	rotor-from-inflow	0.0129695	144.348*	90.0000*
3	rotor-to-volute	0.0129695	44.7939*	89.2497*
3	volute-from-rotor	0.0129695	12.8802	89.2506
3	volute-to-outflow	0.0129695	0.867436	88.0085
3	outflow-from-volute	0.0129695	0.867436	88.0085
3	outflow-out	0.0129695	6.31478 × 10^-9	90.0000
4	inflow-in	0.0118336	90.0001	90.0000
4	inflow-to-rotor	0.0118336	89.6091	90.0000
4	rotor-from-inflow	0.0118336	146.805*	90.0000*
4	rotor-to-volute	0.0118336	46.2741*	88.5393*
4	volute-from-rotor	0.0118336	12.2568	88.5400
4	volute-to-outflow	0.0118336	1.05301	88.1053
4	outflow-from-volute	0.0118336	1.05301	88.1053
4	outflow-out	0.0118336	-1.95640 × 10^-9	90.0000
5	inflow-in	0.0108772	90.0001	90.0000
5	inflow-to-rotor	0.0108772	89.5768	90.0000
5	rotor-from-inflow	0.0108772	149.044*	90.0000*
5	rotor-to-volute	0.0108772	48.0632*	87.8029*
5	volute-from-rotor	0.0108772	11.7057	87.8041
5	volute-to-outflow	0.0108772	1.22027	87.9754
5	outflow-from-volute	0.0108772	1.22027	87.9754
5	outflow-out	0.0108772	-1.13685 × 10^-8	90.0000
6	inflow-in	0.0100573	90.0001	90.0000
6	inflow-to-rotor	0.0100573	89.5296	90.0000
6	rotor-from-inflow	0.0100573	151.068*	90.0000*
6	rotor-to-volute	0.0100573	49.9174*	87.0516*
6	volute-from-rotor	0.0100573	11.2102	87.0519
6	volute-to-outflow	0.0100573	1.16448	87.9437
6	outflow-from-volute	0.0100573	1.16448	87.9437
6	outflow-out	0.0100573	-1.61000 × 10^-9	90.0000
7	inflow-in	0.00932663	90.0002	90.0000
7	inflow-to-rotor	0.00932663	89.4712	90.0000
7	rotor-from-inflow	0.00932663	152.983*	90.0000*
7	rotor-to-volute	0.00932663	51.7119*	86.2157*
7	volute-from-rotor	0.00932663	10.7654	86.2161
7	volute-to-outflow	0.00932663	0.841011	87.8151
7	outflow-from-volute	0.00932663	0.841011	87.8151
7	outflow-out	0.00932663	-6.84385 × 10^-9	90.0000
8	inflow-in	0.00912976	90.0002	90.0000
8	inflow-to-rotor	0.00912976	89.4236	90.0000
8	rotor-from-inflow	0.00912976	153.468*	90.0000*
8	rotor-to-volute	0.00912976	51.8607*	85.6897*
8	volute-from-rotor	0.00912976	10.6324	85.6893
8	volute-to-outflow	0.00912976	0.466225	87.5749
8	outflow-from-volute	0.00912976	0.466225	87.5749
8	outflow-out	0.00912977	3.33812 × 10^-9	90.0000
9	inflow-in	0.00883750	90.0002	90.0000
9	inflow-to-rotor	0.00883750	89.3409	90.0000
9	rotor-from-inflow	0.00883750	154.219*	90.0000*
9	rotor-to-volute	0.00883750	53.1860*	85.9117*
9	volute-from-rotor	0.00883750	10.4859	85.9106
9	volute-to-outflow	0.00883750	0.966422	87.0621
9	outflow-from-volute	0.00883750	0.966422	87.0621
9	outflow-out	0.00883751	6.77173 × 10^-10	90.0000
10	inflow-in	0.00834859	90.0002	90.0000
10	inflow-to-rotor	0.00834859	89.1065	90.0000
10	rotor-from-inflow	0.00834859	155.405*	90.0000*
10	rotor-to-volute	0.00834860	54.4382*	84.8731*
10	volute-from-rotor	0.00834860	9.85495	84.8713
10	volute-to-outflow	0.00834859	1.46319	85.4321
10	outflow-from-volute	0.00834859	1.46319	85.4321
10	outflow-out	0.00834846	-7.80115 × 10^-9	90.0000

(*) Calculated from the relative velocity.

Simulation Stats

Test Case Name

eveningTest

Number of Points [ – ]

10

Machine Type

fan

Rotation Speed [ RPM ]

2200.00

Number of Components [ – ]

(topology)

4

Mesh Size [ cells ]

(details)

inflow : 548

rotor : 4510

volute : 1307

outflow : 880

Total : 7245

Mesh details [ mm ]:

Component	Property	Min	Max	Avg
1	cellOpenness	N/A	1.80288 × 10^-16	N/A
1	cellVolume	30.4723	84.9632	N/A
1	faceArea	4.50018	42.4776	N/A
1	aspectRatio	N/A	5.33397	N/A
1	nonOrthogonality	N/A	32.1432	8.12137
1	skewness	N/A	0.312262	N/A
1	edgeLength	N/A	N/A	N/A
1	concaveAngle	N/A	N/A	N/A
1	faceFlatness	1.00000	N/A	1.00000
1	cellDeterminant	0	N/A	4.39390 × 10^-35
1	faceInterpolationWeight	0.340285	N/A	0.463935
1	faceVolumeRatio	0.515806	0.872343	N/A
1	Warnings:	548 under-determined cells
2	cellOpenness	N/A	2.09901 × 10^-16	N/A
2	cellVolume	0.737859	66.2244	N/A
2	faceArea	0.108968	42.9778	N/A
2	aspectRatio	N/A	41.0796	N/A
2	nonOrthogonality	N/A	34.9651	9.99134
2	skewness	N/A	0.420690	N/A
2	edgeLength	N/A	N/A	N/A
2	concaveAngle	N/A	N/A	N/A
2	faceFlatness	1.00000	N/A	1.00000
2	cellDeterminant	0	N/A	1.23242 × 10^-35
2	faceInterpolationWeight	0.186108	N/A	0.420993
2	faceVolumeRatio	0.228663	0.745721	N/A
2	Warnings:	4510 under-determined cells
3	cellOpenness	N/A	2.01308 × 10^-16	N/A
3	cellVolume	6.91739	842.852	N/A
3	faceArea	1.02157	128.259	N/A
3	aspectRatio	N/A	12.7867	N/A
3	nonOrthogonality	N/A	32.6687	9.65405
3	skewness	N/A	0.375026	N/A
3	edgeLength	N/A	N/A	N/A
3	concaveAngle	N/A	N/A	N/A
3	faceFlatness	1.00000	N/A	1.00000
3	cellDeterminant	0	N/A	1.60410 × 10^-34
3	faceInterpolationWeight	0.233563	N/A	0.437964
3	faceVolumeRatio	0.304738	0.792691	N/A
3	Warnings:	1307 under-determined cells
4	cellOpenness	N/A	2.05061 × 10^-16	N/A
4	cellVolume	115.708	1863.55	N/A
4	faceArea	17.0879	275.211	N/A
4	aspectRatio	N/A	6.72205	N/A
4	nonOrthogonality	N/A	2.94739	0.628992
4	skewness	N/A	0.128718	N/A
4	edgeLength	N/A	N/A	N/A
4	concaveAngle	N/A	N/A	N/A
4	faceFlatness	1.00000	N/A	1.00000
4	cellDeterminant	0	N/A	4.94519 × 10^-38
4	faceInterpolationWeight	0.326697	N/A	0.469620
4	faceVolumeRatio	0.485215	0.892660	N/A
4	Warnings:	880 under-determined cells

Average y+ at walls [ – ]
(details)

216.095

Wall-clock time [ hh:mm:ss ]

00:02:28

Parallel Processors [ – ]

6

Fluid Name

air

Compressibility

incompressible

Fan Characteristic

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow number [ – ]	Compression number [ – ]
1	0.0714063	2.05540
2	0.0636939	2.09719
3	0.0574517	2.10121
4	0.0524201	2.08428
5	0.0481833	2.04874
6	0.0445532	2.00102
7	0.0413144	1.93852
8	0.0404598	1.90512
9	0.0391673	1.84539
10	0.0369719	1.72481

Efficiency

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Efficiency [ – ]
1	0.0177371	0.501776
2	0.0158214	0.543011
3	0.0142708	0.572312
4	0.0130210	0.592803
5	0.0119686	0.605947
6	0.0110669	0.612521
7	0.0102624	0.612697
8	0.0100501	0.606638
9	0.00972905	0.594391
10	0.00918371	0.565397

Torque

Point Nr.	Torque [ N.m ]
1	0.0491750
2	0.0413516
3	0.0354550
4	0.0309793
5	0.0273825
6	0.0244646
7	0.0219717
8	0.0213581
9	0.0204408
10	0.0189634

Axial Force

Point Nr.	Axial Force [ N ]
1	7.21772 × 10^-17
2	7.22246 × 10^-17
3	7.22597 × 10^-17
4	7.22879 × 10^-17
5	7.23092 × 10^-17
6	7.23279 × 10^-17
7	7.23444 × 10^-17
8	7.23481 × 10^-17
9	7.23514 × 10^-17
10	7.23553 × 10^-17

Total Pressure Difference

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Total Pressure Difference [ Pa ]
1	0.0177371	320.734
2	0.0158214	327.255
3	0.0142708	327.882
4	0.0130210	325.241
5	0.0119686	319.694
6	0.0110669	312.247
7	0.0102624	302.495
8	0.0100501	297.283
9	0.00972905	287.962
10	0.00918371	269.147

Total Pressure per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Total Pressure [ Pa ]
1	inflow-in	0.0177371	101325.
1	inflow-to-rotor	0.0177371	101319.
1	rotor-from-inflow	0.0177371	101319.
1	rotor-to-volute	0.0177371	101706.
1	volute-from-rotor	0.0177371	101706.
1	volute-to-outflow	0.0177371	101664.
1	outflow-from-volute	0.0177371	101664.
1	outflow-out	0.0177371	101646.
2	inflow-in	0.0158214	101325.
2	inflow-to-rotor	0.0158214	101320.
2	rotor-from-inflow	0.0158214	101320.
2	rotor-to-volute	0.0158214	101703.
2	volute-from-rotor	0.0158214	101703.
2	volute-to-outflow	0.0158214	101667.
2	outflow-from-volute	0.0158214	101667.
2	outflow-out	0.0158214	101652.
3	inflow-in	0.0142708	101325.
3	inflow-to-rotor	0.0142708	101321.
3	rotor-from-inflow	0.0142708	101321.
3	rotor-to-volute	0.0142708	101697.
3	volute-from-rotor	0.0142708	101697.
3	volute-to-outflow	0.0142708	101665.
3	outflow-from-volute	0.0142708	101665.
3	outflow-out	0.0142708	101653.
4	inflow-in	0.0130210	101325.
4	inflow-to-rotor	0.0130210	101322.
4	rotor-from-inflow	0.0130210	101322.
4	rotor-to-volute	0.0130210	101688.
4	volute-from-rotor	0.0130210	101688.
4	volute-to-outflow	0.0130210	101660.
4	outflow-from-volute	0.0130210	101660.
4	outflow-out	0.0130210	101650.
5	inflow-in	0.0119686	101325.
5	inflow-to-rotor	0.0119686	101322.
5	rotor-from-inflow	0.0119686	101322.
5	rotor-to-volute	0.0119686	101677.
5	volute-from-rotor	0.0119686	101677.
5	volute-to-outflow	0.0119686	101653.
5	outflow-from-volute	0.0119686	101653.
5	outflow-out	0.0119686	101645.
6	inflow-in	0.0110669	101325.
6	inflow-to-rotor	0.0110669	101323.
6	rotor-from-inflow	0.0110669	101323.
6	rotor-to-volute	0.0110669	101667.
6	volute-from-rotor	0.0110669	101667.
6	volute-to-outflow	0.0110669	101645.
6	outflow-from-volute	0.0110669	101645.
6	outflow-out	0.0110669	101637.
7	inflow-in	0.0102624	101325.
7	inflow-to-rotor	0.0102624	101323.
7	rotor-from-inflow	0.0102624	101323.
7	rotor-to-volute	0.0102624	101655.
7	volute-from-rotor	0.0102624	101655.
7	volute-to-outflow	0.0102624	101636.
7	outflow-from-volute	0.0102624	101636.
7	outflow-out	0.0102624	101628.
8	inflow-in	0.0100501	101325.
8	inflow-to-rotor	0.0100501	101323.
8	rotor-from-inflow	0.0100501	101323.
8	rotor-to-volute	0.0100501	101652.
8	volute-from-rotor	0.0100501	101652.
8	volute-to-outflow	0.0100501	101633.
8	outflow-from-volute	0.0100501	101633.
8	outflow-out	0.0100501	101622.
9	inflow-in	0.00972905	101325.
9	inflow-to-rotor	0.00972905	101323.
9	rotor-from-inflow	0.00972905	101323.
9	rotor-to-volute	0.00972905	101649.
9	volute-from-rotor	0.00972905	101649.
9	volute-to-outflow	0.00972905	101625.
9	outflow-from-volute	0.00972905	101625.
9	outflow-out	0.00972905	101613.
10	inflow-in	0.00918371	101325.
10	inflow-to-rotor	0.00918371	101323.
10	rotor-from-inflow	0.00918371	101323.
10	rotor-to-volute	0.00918372	101639.
10	volute-from-rotor	0.00918372	101639.
10	volute-to-outflow	0.00918371	101610.
10	outflow-from-volute	0.00918371	101610.
10	outflow-out	0.00918361	101594.

Velocity Magnitude per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Velocity Magnitude [ m/s ]
1	inflow-in	0.0177371	14.9351
1	inflow-to-rotor	0.0177371	11.1146
1	rotor-from-inflow	0.0177371	11.1146
1	rotor-to-volute	0.0177371	30.8381
1	volute-from-rotor	0.0177371	30.8384
1	volute-to-outflow	0.0177371	25.4038
1	outflow-from-volute	0.0177371	25.4038
1	outflow-out	0.0177371	18.6748
2	inflow-in	0.0158214	13.2738
2	inflow-to-rotor	0.0158214	9.87657
2	rotor-from-inflow	0.0158214	9.87657
2	rotor-to-volute	0.0158214	28.8761
2	volute-from-rotor	0.0158214	28.8763
2	volute-to-outflow	0.0158214	22.5919
2	outflow-from-volute	0.0158214	22.5919
2	outflow-out	0.0158214	16.4215
3	inflow-in	0.0142708	11.9137
3	inflow-to-rotor	0.0142708	8.86593
3	rotor-from-inflow	0.0142708	8.86593
3	rotor-to-volute	0.0142708	27.2975
3	volute-from-rotor	0.0142708	27.2979
3	volute-to-outflow	0.0142708	20.3055
3	outflow-from-volute	0.0142708	20.3055
3	outflow-out	0.0142708	14.7341
4	inflow-in	0.0130210	10.8002
4	inflow-to-rotor	0.0130210	8.04129
4	rotor-from-inflow	0.0130210	8.04129
4	rotor-to-volute	0.0130210	25.9085
4	volute-from-rotor	0.0130210	25.9088
4	volute-to-outflow	0.0130210	18.4491
4	outflow-from-volute	0.0130210	18.4491
4	outflow-out	0.0130210	13.4102
5	inflow-in	0.0119686	9.84782
5	inflow-to-rotor	0.0119686	7.33382
5	rotor-from-inflow	0.0119686	7.33382
5	rotor-to-volute	0.0119686	24.6838
5	volute-from-rotor	0.0119686	24.6842
5	volute-to-outflow	0.0119686	16.9350
5	outflow-from-volute	0.0119686	16.9350
5	outflow-out	0.0119686	12.3156
6	inflow-in	0.0110669	9.02687
6	inflow-to-rotor	0.0110669	6.72968
6	rotor-from-inflow	0.0110669	6.72968
6	rotor-to-volute	0.0110669	23.6202
6	volute-from-rotor	0.0110669	23.6204
6	volute-to-outflow	0.0110669	15.7677
6	outflow-from-volute	0.0110669	15.7677
6	outflow-out	0.0110669	11.3887
7	inflow-in	0.0102624	8.28146
7	inflow-to-rotor	0.0102624	6.18196
7	rotor-from-inflow	0.0102624	6.18195
7	rotor-to-volute	0.0102624	22.6152
7	volute-from-rotor	0.0102624	22.6152
7	volute-to-outflow	0.0102624	14.9964
7	outflow-from-volute	0.0102624	14.9964
7	outflow-out	0.0102624	10.5697
8	inflow-in	0.0100501	8.09401
8	inflow-to-rotor	0.0100501	6.05195
8	rotor-from-inflow	0.0100501	6.05193
8	rotor-to-volute	0.0100501	22.3334
8	volute-from-rotor	0.0100501	22.3335
8	volute-to-outflow	0.0100501	15.1239
8	outflow-from-volute	0.0100501	15.1239
8	outflow-out	0.0100501	10.3615
9	inflow-in	0.00972905	7.79942
9	inflow-to-rotor	0.00972905	5.84753
9	rotor-from-inflow	0.00972905	5.84750
9	rotor-to-volute	0.00972905	22.0436
9	volute-from-rotor	0.00972905	22.0434
9	volute-to-outflow	0.00972905	15.4029
9	outflow-from-volute	0.00972905	15.4029
9	outflow-out	0.00972905	10.0853
10	inflow-in	0.00918371	7.30593
10	inflow-to-rotor	0.00918371	5.52580
10	rotor-from-inflow	0.00918371	5.52575
10	rotor-to-volute	0.00918372	21.3152
10	volute-from-rotor	0.00918372	21.3149
10	volute-to-outflow	0.00918371	15.6737
10	outflow-from-volute	0.00918371	15.6737
10	outflow-out	0.00918361	9.64663

Circumferential and Meridional Angle

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Circumferential Angle [ deg ]	Meridional Angle [ deg ]
1	inflow-in	0.0177371	90.0001	90.0000
1	inflow-to-rotor	0.0177371	89.6956	90.0000
1	rotor-from-inflow	0.0177371	138.447*	90.0000*
1	rotor-to-volute	0.0177371	41.4860*	89.6851*
1	volute-from-rotor	0.0177371	14.3669	89.6857
1	volute-to-outflow	0.0177371	-0.738993	88.0800
1	outflow-from-volute	0.0177371	-0.738993	88.0800
1	outflow-out	0.0177371	7.48006 × 10^-9	90.0000
2	inflow-in	0.0158214	90.0001	90.0000
2	inflow-to-rotor	0.0158214	89.6735	90.0000
2	rotor-from-inflow	0.0158214	141.554*	90.0000*
2	rotor-to-volute	0.0158214	43.0638*	89.4146*
2	volute-from-rotor	0.0158214	13.5607	89.4153
2	volute-to-outflow	0.0158214	0.750304	88.0440
2	outflow-from-volute	0.0158214	0.750304	88.0440
2	outflow-out	0.0158214	-9.13736 × 10^-9	90.0000
3	inflow-in	0.0142708	90.0001	90.0000
3	inflow-to-rotor	0.0142708	89.6463	90.0000
3	rotor-from-inflow	0.0142708	144.343*	90.0000*
3	rotor-to-volute	0.0142708	44.7875*	89.2520*
3	volute-from-rotor	0.0142708	12.8821	89.2529
3	volute-to-outflow	0.0142708	0.868785	88.0073
3	outflow-from-volute	0.0142708	0.868785	88.0073
3	outflow-out	0.0142708	5.93600 × 10^-9	90.0000
4	inflow-in	0.0130210	90.0001	90.0000
4	inflow-to-rotor	0.0130210	89.6100	90.0000
4	rotor-from-inflow	0.0130210	146.800*	90.0000*
4	rotor-to-volute	0.0130210	46.2623*	88.5422*
4	volute-from-rotor	0.0130210	12.2583	88.5430
4	volute-to-outflow	0.0130210	1.05472	88.1028
4	outflow-from-volute	0.0130210	1.05472	88.1028
4	outflow-out	0.0130210	4.01785 × 10^-9	90.0000
5	inflow-in	0.0119686	90.0001	90.0000
5	inflow-to-rotor	0.0119686	89.5780	90.0000
5	rotor-from-inflow	0.0119686	149.041*	90.0000*
5	rotor-to-volute	0.0119686	48.0568*	87.8093*
5	volute-from-rotor	0.0119686	11.7072	87.8104
5	volute-to-outflow	0.0119686	1.22371	87.9714
5	outflow-from-volute	0.0119686	1.22371	87.9714
5	outflow-out	0.0119686	5.82459 × 10^-9	90.0000
6	inflow-in	0.0110669	90.0001	90.0000
6	inflow-to-rotor	0.0110669	89.5294	90.0000
6	rotor-from-inflow	0.0110669	151.064*	90.0000*
6	rotor-to-volute	0.0110669	49.8877*	87.0432*
6	volute-from-rotor	0.0110669	11.2108	87.0435
6	volute-to-outflow	0.0110669	1.17081	87.9400
6	outflow-from-volute	0.0110669	1.17081	87.9400
6	outflow-out	0.0110669	1.29256 × 10^-8	90.0000
7	inflow-in	0.0102624	90.0002	90.0000
7	inflow-to-rotor	0.0102624	89.4721	90.0000
7	rotor-from-inflow	0.0102624	152.981*	90.0000*
7	rotor-to-volute	0.0102624	51.7100*	86.2181*
7	volute-from-rotor	0.0102624	10.7668	86.2184
7	volute-to-outflow	0.0102624	0.844648	87.8130
7	outflow-from-volute	0.0102624	0.844648	87.8130
7	outflow-out	0.0102624	1.46537 × 10^-8	90.0000
8	inflow-in	0.0100501	90.0002	90.0000
8	inflow-to-rotor	0.0100501	89.4254	90.0000
8	rotor-from-inflow	0.0100501	153.455*	90.0000*
8	rotor-to-volute	0.0100501	51.8237*	85.6741*
8	volute-from-rotor	0.0100501	10.6311	85.6737
8	volute-to-outflow	0.0100501	0.676359	87.5622
8	outflow-from-volute	0.0100501	0.676359	87.5622
8	outflow-out	0.0100501	-2.00532 × 10^-9	90.0000
9	inflow-in	0.00972905	90.0002	90.0000
9	inflow-to-rotor	0.00972905	89.3464	90.0000
9	rotor-from-inflow	0.00972905	154.210*	90.0000*
9	rotor-to-volute	0.00972905	53.2149*	85.9664*
9	volute-from-rotor	0.00972905	10.5122	85.9653
9	volute-to-outflow	0.00972905	0.945568	87.0731
9	outflow-from-volute	0.00972905	0.945568	87.0731
9	outflow-out	0.00972905	-1.19216 × 10^-9	90.0000
10	inflow-in	0.00918371	90.0002	90.0000
10	inflow-to-rotor	0.00918371	89.1081	90.0000
10	rotor-from-inflow	0.00918371	155.416*	90.0000*
10	rotor-to-volute	0.00918372	54.4871*	84.9073*
10	volute-from-rotor	0.00918372	9.87014	84.9055
10	volute-to-outflow	0.00918371	1.50152	85.3813
10	outflow-from-volute	0.00918371	1.50152	85.3813
10	outflow-out	0.00918361	-9.46715 × 10^-9	90.0000

(*) Calculated from the relative velocity.

Simulation Stats

Test Case Name

eveningTest

Number of Points [ – ]

10

Machine Type

fan

Rotation Speed [ RPM ]

2400.00

Number of Components [ – ]

(topology)

4

Mesh Size [ cells ]

(details)

inflow : 548

rotor : 4510

volute : 1307

outflow : 880

Total : 7245

Mesh details [ mm ]:

Component	Property	Min	Max	Avg
1	cellOpenness	N/A	1.80288 × 10^-16	N/A
1	cellVolume	30.4723	84.9632	N/A
1	faceArea	4.50018	42.4776	N/A
1	aspectRatio	N/A	5.33397	N/A
1	nonOrthogonality	N/A	32.1432	8.12137
1	skewness	N/A	0.312262	N/A
1	edgeLength	N/A	N/A	N/A
1	concaveAngle	N/A	N/A	N/A
1	faceFlatness	1.00000	N/A	1.00000
1	cellDeterminant	0	N/A	4.39390 × 10^-35
1	faceInterpolationWeight	0.340285	N/A	0.463935
1	faceVolumeRatio	0.515806	0.872343	N/A
1	Warnings:	548 under-determined cells
2	cellOpenness	N/A	2.09901 × 10^-16	N/A
2	cellVolume	0.737859	66.2244	N/A
2	faceArea	0.108968	42.9778	N/A
2	aspectRatio	N/A	41.0796	N/A
2	nonOrthogonality	N/A	34.9651	9.99134
2	skewness	N/A	0.420690	N/A
2	edgeLength	N/A	N/A	N/A
2	concaveAngle	N/A	N/A	N/A
2	faceFlatness	1.00000	N/A	1.00000
2	cellDeterminant	0	N/A	1.23242 × 10^-35
2	faceInterpolationWeight	0.186108	N/A	0.420993
2	faceVolumeRatio	0.228663	0.745721	N/A
2	Warnings:	4510 under-determined cells
3	cellOpenness	N/A	2.01308 × 10^-16	N/A
3	cellVolume	6.91739	842.852	N/A
3	faceArea	1.02157	128.259	N/A
3	aspectRatio	N/A	12.7867	N/A
3	nonOrthogonality	N/A	32.6687	9.65405
3	skewness	N/A	0.375026	N/A
3	edgeLength	N/A	N/A	N/A
3	concaveAngle	N/A	N/A	N/A
3	faceFlatness	1.00000	N/A	1.00000
3	cellDeterminant	0	N/A	1.60410 × 10^-34
3	faceInterpolationWeight	0.233563	N/A	0.437964
3	faceVolumeRatio	0.304738	0.792691	N/A
3	Warnings:	1307 under-determined cells
4	cellOpenness	N/A	2.05061 × 10^-16	N/A
4	cellVolume	115.708	1863.55	N/A
4	faceArea	17.0879	275.211	N/A
4	aspectRatio	N/A	6.72205	N/A
4	nonOrthogonality	N/A	2.94739	0.628992
4	skewness	N/A	0.128718	N/A
4	edgeLength	N/A	N/A	N/A
4	concaveAngle	N/A	N/A	N/A
4	faceFlatness	1.00000	N/A	1.00000
4	cellDeterminant	0	N/A	4.94519 × 10^-38
4	faceInterpolationWeight	0.326697	N/A	0.469620
4	faceVolumeRatio	0.485215	0.892660	N/A
4	Warnings:	880 under-determined cells

Average y+ at walls [ – ]
(details)

234.919

Wall-clock time [ hh:mm:ss ]

00:02:28

Parallel Processors [ – ]

6

Fluid Name

air

Compressibility

incompressible

Fan Characteristic

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow number [ – ]	Compression number [ – ]
1	0.0714370	2.05728
2	0.0637173	2.09872
3	0.0574681	2.10237
4	0.0524336	2.08529
5	0.0481994	2.05000
6	0.0445654	2.00199
7	0.0413259	1.93946
8	0.0404881	1.90762
9	0.0391972	1.84784
10	0.0369598	1.72422

Efficiency

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Efficiency [ – ]
1	0.0193579	0.502046
2	0.0172661	0.543184
3	0.0155726	0.572447
4	0.0142084	0.592923
5	0.0130610	0.606186
6	0.0120763	0.612685
7	0.0111985	0.612858
8	0.0109714	0.607204
9	0.0106216	0.594981
10	0.0100153	0.565279

Torque

Point Nr.	Torque [ N.m ]
1	0.0585611
2	0.0492419
3	0.0422123
4	0.0368810
5	0.0325996
6	0.0291239
7	0.0261567
8	0.0254409
9	0.0243489
10	0.0225542

Axial Force

Point Nr.	Axial Force [ N ]
1	7.21321 × 10^-17
2	7.21882 × 10^-17
3	7.22305 × 10^-17
4	7.22641 × 10^-17
5	7.22911 × 10^-17
6	7.23116 × 10^-17
7	7.23313 × 10^-17
8	7.23357 × 10^-17
9	7.23397 × 10^-17
10	7.23445 × 10^-17

Total Pressure Difference

1:pressure-inlet — 4:pressure-outlet

Point Nr.	Flow Rate [ m³/s ]	Total Pressure Difference [ Pa ]
1	0.0193579	382.049
2	0.0172661	389.745
3	0.0155726	390.422
4	0.0142084	387.250
5	0.0130610	380.696
6	0.0120763	371.781
7	0.0111985	360.169
8	0.0109714	354.257
9	0.0106216	343.154
10	0.0100153	320.197

Total Pressure per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Total Pressure [ Pa ]
1	inflow-in	0.0193579	101325.
1	inflow-to-rotor	0.0193579	101318.
1	rotor-from-inflow	0.0193579	101318.
1	rotor-to-volute	0.0193579	101779.
1	volute-from-rotor	0.0193579	101779.
1	volute-to-outflow	0.0193579	101728.
1	outflow-from-volute	0.0193579	101728.
1	outflow-out	0.0193579	101707.
2	inflow-in	0.0172661	101325.
2	inflow-to-rotor	0.0172661	101319.
2	rotor-from-inflow	0.0172661	101319.
2	rotor-to-volute	0.0172661	101775.
2	volute-from-rotor	0.0172661	101775.
2	volute-to-outflow	0.0172661	101732.
2	outflow-from-volute	0.0172661	101732.
2	outflow-out	0.0172661	101715.
3	inflow-in	0.0155726	101325.
3	inflow-to-rotor	0.0155726	101320.
3	rotor-from-inflow	0.0155726	101320.
3	rotor-to-volute	0.0155726	101768.
3	volute-from-rotor	0.0155726	101768.
3	volute-to-outflow	0.0155726	101730.
3	outflow-from-volute	0.0155726	101730.
3	outflow-out	0.0155726	101715.
4	inflow-in	0.0142084	101325.
4	inflow-to-rotor	0.0142084	101321.
4	rotor-from-inflow	0.0142084	101321.
4	rotor-to-volute	0.0142084	101757.
4	volute-from-rotor	0.0142084	101757.
4	volute-to-outflow	0.0142084	101724.
4	outflow-from-volute	0.0142084	101724.
4	outflow-out	0.0142084	101712.
5	inflow-in	0.0130610	101325.
5	inflow-to-rotor	0.0130610	101322.
5	rotor-from-inflow	0.0130610	101322.
5	rotor-to-volute	0.0130610	101744.
5	volute-from-rotor	0.0130610	101744.
5	volute-to-outflow	0.0130610	101716.
5	outflow-from-volute	0.0130610	101716.
5	outflow-out	0.0130610	101706.
6	inflow-in	0.0120763	101325.
6	inflow-to-rotor	0.0120763	101322.
6	rotor-from-inflow	0.0120763	101322.
6	rotor-to-volute	0.0120763	101732.
6	volute-from-rotor	0.0120763	101732.
6	volute-to-outflow	0.0120763	101706.
6	outflow-from-volute	0.0120763	101706.
6	outflow-out	0.0120763	101697.
7	inflow-in	0.0111985	101325.
7	inflow-to-rotor	0.0111985	101323.
7	rotor-from-inflow	0.0111985	101323.
7	rotor-to-volute	0.0111985	101718.
7	volute-from-rotor	0.0111985	101718.
7	volute-to-outflow	0.0111985	101696.
7	outflow-from-volute	0.0111985	101696.
7	outflow-out	0.0111985	101685.
8	inflow-in	0.0109714	101325.
8	inflow-to-rotor	0.0109714	101323.
8	rotor-from-inflow	0.0109714	101323.
8	rotor-to-volute	0.0109714	101714.
8	volute-from-rotor	0.0109714	101714.
8	volute-to-outflow	0.0109714	101691.
8	outflow-from-volute	0.0109714	101691.
8	outflow-out	0.0109714	101679.
9	inflow-in	0.0106216	101325.
9	inflow-to-rotor	0.0106216	101323.
9	rotor-from-inflow	0.0106216	101323.
9	rotor-to-volute	0.0106216	101710.
9	volute-from-rotor	0.0106216	101710.
9	volute-to-outflow	0.0106216	101683.
9	outflow-from-volute	0.0106216	101683.
9	outflow-out	0.0106216	101668.
10	inflow-in	0.0100153	101325.
10	inflow-to-rotor	0.0100153	101323.
10	rotor-from-inflow	0.0100153	101323.
10	rotor-to-volute	0.0100153	101699.
10	volute-from-rotor	0.0100153	101699.
10	volute-to-outflow	0.0100153	101664.
10	outflow-from-volute	0.0100153	101664.
10	outflow-out	0.0100152	101645.

Velocity Magnitude per Interfaces

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Velocity Magnitude [ m/s ]
1	inflow-in	0.0193579	16.2994
1	inflow-to-rotor	0.0193579	12.1297
1	rotor-from-inflow	0.0193579	12.1297
1	rotor-to-volute	0.0193579	33.6499
1	volute-from-rotor	0.0193579	33.6502
1	volute-to-outflow	0.0193579	27.7253
1	outflow-from-volute	0.0193579	27.7253
1	outflow-out	0.0193579	20.3818
2	inflow-in	0.0172661	14.4865
2	inflow-to-rotor	0.0172661	10.7788
2	rotor-from-inflow	0.0172661	10.7788
2	rotor-to-volute	0.0172661	31.5100
2	volute-from-rotor	0.0172661	31.5103
2	volute-to-outflow	0.0172661	24.6535
2	outflow-from-volute	0.0172661	24.6535
2	outflow-out	0.0172661	17.9211
3	inflow-in	0.0155726	13.0001
3	inflow-to-rotor	0.0155726	9.67424
3	rotor-from-inflow	0.0155726	9.67424
3	rotor-to-volute	0.0155726	29.7831
3	volute-from-rotor	0.0155726	29.7836
3	volute-to-outflow	0.0155726	22.1578
3	outflow-from-volute	0.0155726	22.1578
3	outflow-out	0.0155726	16.0782
4	inflow-in	0.0142084	11.7843
4	inflow-to-rotor	0.0142084	8.77381
4	rotor-from-inflow	0.0142084	8.77381
4	rotor-to-volute	0.0142084	28.2668
4	volute-from-rotor	0.0142084	28.2671
4	volute-to-outflow	0.0142084	20.1315
4	outflow-from-volute	0.0142084	20.1315
4	outflow-out	0.0142084	14.6330
5	inflow-in	0.0130610	10.7431
5	inflow-to-rotor	0.0130610	8.00036
5	rotor-from-inflow	0.0130610	8.00036
5	rotor-to-volute	0.0130610	26.9289
5	volute-from-rotor	0.0130610	26.9293
5	volute-to-outflow	0.0130610	18.4803
5	outflow-from-volute	0.0130610	18.4803
5	outflow-out	0.0130610	13.4394
6	inflow-in	0.0120763	9.84905
6	inflow-to-rotor	0.0120763	7.34206
6	rotor-from-inflow	0.0120763	7.34205
6	rotor-to-volute	0.0120763	25.7707
6	volute-from-rotor	0.0120763	25.7709
6	volute-to-outflow	0.0120763	17.2064
6	outflow-from-volute	0.0120763	17.2064
6	outflow-out	0.0120763	12.4269
7	inflow-in	0.0111985	9.03561
7	inflow-to-rotor	0.0111985	6.74463
7	rotor-from-inflow	0.0111985	6.74461
7	rotor-to-volute	0.0111985	24.6720
7	volute-from-rotor	0.0111985	24.6721
7	volute-to-outflow	0.0111985	16.3619
7	outflow-from-volute	0.0111985	16.3619
7	outflow-out	0.0111985	11.5335
8	inflow-in	0.0109714	8.83527
8	inflow-to-rotor	0.0109714	6.60566
8	rotor-from-inflow	0.0109714	6.60564
8	rotor-to-volute	0.0109714	24.3707
8	volute-from-rotor	0.0109714	24.3708
8	volute-to-outflow	0.0109714	16.4827
8	outflow-from-volute	0.0109714	16.4827
8	outflow-out	0.0109714	11.3111
9	inflow-in	0.0106216	8.51451
9	inflow-to-rotor	0.0106216	6.38283
9	rotor-from-inflow	0.0106216	6.38280
9	rotor-to-volute	0.0106216	24.0568
9	volute-from-rotor	0.0106216	24.0565
9	volute-to-outflow	0.0106216	16.7977
9	outflow-from-volute	0.0106216	16.7977
9	outflow-out	0.0106216	11.0095
10	inflow-in	0.0100153	7.96451
10	inflow-to-rotor	0.0100153	6.02350
10	rotor-from-inflow	0.0100153	6.02345
10	rotor-to-volute	0.0100153	23.2477
10	volute-from-rotor	0.0100153	23.2474
10	volute-to-outflow	0.0100153	17.1011
10	outflow-from-volute	0.0100153	17.1011
10	outflow-out	0.0100152	10.5205

Circumferential and Meridional Angle

Point Nr.	Interface Name	Flow Rate [ m³/s ]	Circumferential Angle [ deg ]	Meridional Angle [ deg ]
1	inflow-in	0.0193579	90.0001	90.0000
1	inflow-to-rotor	0.0193579	89.6962	90.0000
1	rotor-from-inflow	0.0193579	138.438*	90.0000*
1	rotor-to-volute	0.0193579	41.4814*	89.6867*
1	volute-from-rotor	0.0193579	14.3683	89.6874
1	volute-to-outflow	0.0193579	-0.738864	88.0798
1	outflow-from-volute	0.0193579	-0.738864	88.0798
1	outflow-out	0.0193579	8.41256 × 10^-9	90.0000
2	inflow-in	0.0172661	90.0001	90.0000
2	inflow-to-rotor	0.0172661	89.6739	90.0000
2	rotor-from-inflow	0.0172661	141.544*	90.0000*
2	rotor-to-volute	0.0172661	43.0506*	89.4184*
2	volute-from-rotor	0.0172661	13.5618	89.4191
2	volute-to-outflow	0.0172661	0.751723	88.0435
2	outflow-from-volute	0.0172661	0.751723	88.0435
2	outflow-out	0.0172661	-1.01595 × 10^-8	90.0000
3	inflow-in	0.0155726	90.0001	90.0000
3	inflow-to-rotor	0.0155726	89.6470	90.0000
3	rotor-from-inflow	0.0155726	144.337*	90.0000*
3	rotor-to-volute	0.0155726	44.7914*	89.2541*
3	volute-from-rotor	0.0155726	12.8838	89.2549
3	volute-to-outflow	0.0155726	0.869633	88.0066
3	outflow-from-volute	0.0155726	0.869633	88.0066
3	outflow-out	0.0155726	-6.98851 × 10^-9	90.0000
4	inflow-in	0.0142084	90.0001	90.0000
4	inflow-to-rotor	0.0142084	89.6109	90.0000
4	rotor-from-inflow	0.0142084	146.796*	90.0000*
4	rotor-to-volute	0.0142084	46.2692*	88.5469*
4	volute-from-rotor	0.0142084	12.2600	88.5476
4	volute-to-outflow	0.0142084	1.05541	88.1013
4	outflow-from-volute	0.0142084	1.05541	88.1013
4	outflow-out	0.0142084	-1.16847 × 10^-8	90.0000
5	inflow-in	0.0130610	90.0001	90.0000
5	inflow-to-rotor	0.0130610	89.5803	90.0000
5	rotor-from-inflow	0.0130610	149.041*	90.0000*
5	rotor-to-volute	0.0130610	48.0247*	87.8085*
5	volute-from-rotor	0.0130610	11.7073	87.8096
5	volute-to-outflow	0.0130610	1.22409	87.9707
5	outflow-from-volute	0.0130610	1.22409	87.9707
5	outflow-out	0.0130610	-9.90797 × 10^-9	90.0000
6	inflow-in	0.0120763	90.0001	90.0000
6	inflow-to-rotor	0.0120763	89.5309	90.0000
6	rotor-from-inflow	0.0120763	151.061*	90.0000*
6	rotor-to-volute	0.0120763	49.8941*	87.0580*
6	volute-from-rotor	0.0120763	11.2113	87.0582
6	volute-to-outflow	0.0120763	1.17162	87.9360
6	outflow-from-volute	0.0120763	1.17162	87.9360
6	outflow-out	0.0120763	-3.68442 × 10^-9	90.0000
7	inflow-in	0.0111985	90.0002	90.0000
7	inflow-to-rotor	0.0111985	89.4730	90.0000
7	rotor-from-inflow	0.0111985	152.978*	90.0000*
7	rotor-to-volute	0.0111985	51.7072*	86.2214*
7	volute-from-rotor	0.0111985	10.7692	86.2217
7	volute-to-outflow	0.0111985	0.847611	87.8117
7	outflow-from-volute	0.0111985	0.847611	87.8117
7	outflow-out	0.0111985	-1.81955 × 10^-8	90.0000
8	inflow-in	0.0109714	90.0002	90.0000
8	inflow-to-rotor	0.0109714	89.4276	90.0000
8	rotor-from-inflow	0.0109714	153.442*	90.0000*
8	rotor-to-volute	0.0109714	51.8087*	85.6822*
8	volute-from-rotor	0.0109714	10.6343	85.6818
8	volute-to-outflow	0.0109714	0.834584	87.5683
8	outflow-from-volute	0.0109714	0.834584	87.5683
8	outflow-out	0.0109714	-1.42071 × 10^-9	90.0000
9	inflow-in	0.0106216	90.0002	90.0000
9	inflow-to-rotor	0.0106216	89.3495	90.0000
9	rotor-from-inflow	0.0106216	154.197*	90.0000*
9	rotor-to-volute	0.0106216	53.2626*	86.0085*
9	volute-from-rotor	0.0106216	10.5276	86.0074
9	volute-to-outflow	0.0106216	0.922268	87.0831
9	outflow-from-volute	0.0106216	0.922268	87.0831
9	outflow-out	0.0106216	-1.64909 × 10^-9	90.0000
10	inflow-in	0.0100153	90.0002	90.0000
10	inflow-to-rotor	0.0100153	89.1088	90.0000
10	rotor-from-inflow	0.0100153	155.431*	90.0000*
10	rotor-to-volute	0.0100153	54.5441*	84.9288*
10	volute-from-rotor	0.0100153	9.87581	84.9270
10	volute-to-outflow	0.0100153	1.52021	85.3192
10	outflow-from-volute	0.0100153	1.52021	85.3192
10	outflow-out	0.0100152	5.94708 × 10^-9	90.0000

(*) Calculated from the relative velocity.

Hi, this is steady-state CFD simulation report of: eveningTest

Speedline #1

Speedline #2

Speedline #3

Speedline #4

Hi, this is steady-state CFD simulation report of:

eveningTest
