Test Case Name |
room-heat-transfer-full-test |
Number of Points [ – ] |
1 |
Machine Type |
stator |
Rotation Speed [ RPM ] |
0 |
Number of Components [ – ] (topology) |
1 |
Mesh Size [ cells ] (details) |
Co1 : 2741660
Total : 2741660 |
Mesh details [ mm ]:
Component |
Property |
Min |
Max |
Avg |
1 |
cellOpenness |
N/A |
8.29531 × 10-16
|
N/A |
1 |
cellVolume |
0.235961 |
1.09589 × 106
|
N/A |
1 |
faceArea |
0.0396678 |
11829.0 |
N/A |
1 |
aspectRatio |
N/A |
26.5721 |
N/A |
1 |
nonOrthogonality |
N/A |
64.9551 |
10.4992 |
1 |
skewness |
N/A |
6.78927 |
N/A |
1 |
edgeLength |
0 |
117.898 |
N/A |
1 |
concaveAngle |
N/A |
79.8570 |
N/A |
1 |
faceFlatness |
0.132836 |
N/A |
0.998983 |
1 |
cellDeterminant |
2.49361 × 10-4
|
N/A |
12.7439 |
1 |
faceInterpolationWeight |
0.0200984 |
N/A |
0.457191 |
1 |
faceVolumeRatio |
0.0108328 |
0.805853 |
N/A |
1 |
Warnings: |
3 skew faces
3354 faces with low quality or negative volume decomposition tets
4 points on short edges
12763 faces with concave angles
140 warped faces
20 under-determined cells
139183 concave cells
216 faces with low interpolation weights
|
|
Average y+ at walls [ – ] (details) |
y+ details:
Point |
Patch |
Min |
Max |
Avg |
1 |
Co1_Window_wall |
0.634145 |
8.34073 |
6.14519 |
1 |
Co1_InnerSurface3-Fan-Coil_wall |
0.945282 |
3.73299 |
1.99395 |
1 |
Co1_Surface2-in2-Room_wall |
0.305484 |
8.82055 |
3.41035 |
1 |
Co1_Fan-Coil-Bottom_wall |
0.0966429 |
5.08452 |
1.36993 |
1 |
Co1_Surface1-in1-Room_wall |
0.720649 |
7.02221 |
4.34978 |
1 |
Co1_CoffeeMug1_wall |
0.0240897 |
4.20128 |
0.867478 |
1 |
Co1_Wall-outside-Room_wall |
0.154086 |
12.4971 |
4.09190 |
1 |
Co1_Woman1_wall |
0.0734040 |
7.73229 |
1.49022 |
1 |
Co1_Table_wall |
0.00154219 |
5.92001 |
0.393379 |
1 |
Co1_InnerSurface2-Fan-Coil_wall |
1.14521 |
3.78111 |
1.95187 |
1 |
Co1_Fan-Coil-Top_wall |
0.632211 |
5.71343 |
2.79103 |
1 |
Co1_Surface3-in3-Room_wall |
0.505828 |
8.32959 |
4.20172 |
1 |
Co1_BeerMug_wall |
0.0405701 |
2.63958 |
0.880027 |
1 |
Co1_Top-Room_wall |
0.906478 |
14.0925 |
7.90249 |
1 |
Co1_Chair_wall |
0.0222060 |
7.48055 |
0.338679 |
1 |
Co1_Floor-Room_wall |
0.0186658 |
10.3042 |
1.70180 |
1 |
Co1_Woman2_wall |
0.0321343 |
7.16364 |
1.45691 |
1 |
Co1_InnerSurface1-Fan-Coil_wall |
0.576383 |
6.22468 |
2.03803 |
1 |
Co1_CoffeePot_wall |
0.0605562 |
4.88216 |
0.996329 |
1 |
Co1_CoffeeMug2_wall |
0.0457810 |
4.17805 |
0.843096 |
1 |
Co1_Man_wall |
0.0234781 |
9.82320 |
1.16765 |
1 |
Co1_Couch_wall |
0.0125534 |
4.41921 |
0.529997 |
|
Wall-clock time [ hh:mm:ss ] |
08:06:15 |
Parallel Processors [ – ] |
24 |
Fluid Name |
air |
Physical Model |
heat transfer |
Equation of state |
Boussinesq |
Numerical order |
first |
Turbulence model |
kOmegaSST |
