Hi, this is steady-state FEA simulation report of:

ship-full-1

Created by TFEA 21.02 on Mon Mar 8 19:29:04 2021

General Settings

Fluid-Structure Interaction Performed	yes
Thermal Effects Considered	no
Source for FSI	This TCFD Case
Rotates with CFD frame	static

Material Descrtiption

Name	steel
Density [ kg/m³ ]	7800.00
Type	isotropic
Young Modulus [ GPa ]	210.000
Poisson Ratio [ - ]	0.300000

Solver

Finite Element Order	2
Nonlinear Governing Equation
Eigenmodes for Deformed Solid	no

Mesh Statistics

Number of Points	N/A
Number of Elements	N/A
Number of Surface Elements	N/A
Shortest Edge [ mm ]	N/A
Longest Edge [ mm ]	N/A
Minimal Angle Between Edges [ deg ]	N/A
Maximal Angle Between Edges [ deg ]	N/A
Minimal Angle Between Faces [ deg ]	N/A
Maximal Angle Between Faces [ deg ]	N/A

Speedline #1 Point #1

Run time information

Wall time [ hh:mm:ss ]

00:00:08

Static Analysis

Quantity	Value	Node	X-coordinate	Y-coordinate	Z-coordinate
MaxDispAbs [ mm ]	0.0306192	376	0.122250	0.0500433	0.243390
MinDispAbs [ mm ]	0	11	0.180890	0.0214616	0.123006
MaxDispX [ mm ]	0.0259073	376	0.122250	0.0500433	0.243390
MinDispX [ mm ]	-9.62385 × 10^-5	9953	0.163932	0.00483746	0.0954152
MaxDispY [ mm ]	0.0148977	375	0.123549	0.0457225	0.245396
MinDispY [ mm ]	-0.0149491	131	0.120908	0.0215674	0.00814328
MaxDispX [ mm ]	0.0136508	214	0.119520	-0.109992	0.0763221
MinDispZ [ mm ]	-0.0150133	47	0.122250	0.123542	0.117273
MaxMises [ MPa ]	3.98987	15003	0.131794	0.0164117	0.215307
MinMises [ MPa ]	2.20443 × 10^-7	13553	0.180890	-0.0213332	0.136453
MaxPrincipleStress [ MPa ]	3.41640	2472	0.117533	0.0137095	0.0518276
MinPrincipleStress [ MPa ]	-4.77975	9847	0.145842	-0.0148557	0.112946

Frequency Analysis

Mode Nr.	Eigenvalue	Frequency - Real Part	Frequency - Imaginary Part
1	3.83225 × 10⁷	6190.52	0
2	3.90601 × 10⁷	6249.81	0
3	3.90981 × 10⁷	6252.85	0

Participation Factor

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	-0.476195	-0.00685810	0.0138973	0.0426924	-0.0639670	6.06149 × 10^-4
2	0.0227678	-0.0579263	0.310497	0.00554022	-0.0364414	0.0238661
3	-0.00644034	0.311102	0.0592949	-0.0398030	0.0229047	0.0394986

Effective Modal Mass

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	0.226761	4.70335 × 10^-5	1.93136 × 10^-4	0.00182264	0.00409178	3.67417 × 10^-7
2	5.18371 × 10^-4	0.00335546	0.0964081	3.06940 × 10^-5	0.00132797	5.69589 × 10^-4
3	4.14780 × 10^-5	0.0967846	0.00351588	0.00158428	5.24623 × 10^-4	0.00156014
Total	0.227321	0.100187	0.100117	0.00343762	0.00594438	0.00213010

Total Effective Mass

Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
2.30176	2.30176	2.30176	0.0437573	0.0848404	0.0460895

Speedline #1 Point #2

Run time information

Wall time [ hh:mm:ss ]

00:00:08

Static Analysis

Quantity	Value	Node	X-coordinate	Y-coordinate	Z-coordinate
MaxDispAbs [ mm ]	0.0246297	376	0.122250	0.0500433	0.243390
MinDispAbs [ mm ]	0	11	0.180890	0.0214616	0.123006
MaxDispX [ mm ]	0.0206686	376	0.122250	0.0500433	0.243390
MinDispX [ mm ]	-7.98314 × 10^-5	178	0.163629	0.00461017	0.0978689
MaxDispY [ mm ]	0.0122666	375	0.123549	0.0457225	0.245396
MinDispY [ mm ]	-0.0115447	131	0.120908	0.0215674	0.00814328
MaxDispX [ mm ]	0.0107347	214	0.119520	-0.109992	0.0763221
MinDispZ [ mm ]	-0.0117554	48	0.123549	0.124115	0.122002
MaxMises [ MPa ]	3.15884	18337	0.135569	0.00882977	0.205591
MinMises [ MPa ]	1.87064 × 10^-7	13553	0.180890	-0.0213332	0.136453
MaxPrincipleStress [ MPa ]	2.71817	18562	0.127828	0.0143916	0.205002
MinPrincipleStress [ MPa ]	-3.95347	9847	0.145842	-0.0148557	0.112946

Frequency Analysis

Mode Nr.	Eigenvalue	Frequency - Real Part	Frequency - Imaginary Part
1	3.83235 × 10⁷	6190.59	0
2	3.90630 × 10⁷	6250.04	0
3	3.90984 × 10⁷	6252.87	0

Participation Factor

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	-0.476180	-0.00702359	0.0141163	0.0427116	-0.0640068	6.07315 × 10^-4
2	0.0228565	-0.0460917	0.312507	0.00400938	-0.0354509	0.0253565
3	-0.00755877	0.313276	0.0471068	-0.0399928	0.0242789	0.0385462

Effective Modal Mass

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	0.226748	4.93308 × 10^-5	1.99269 × 10^-4	0.00182428	0.00409687	3.68831 × 10^-7
2	5.22417 × 10^-4	0.00212444	0.0976603	1.60752 × 10^-5	0.00125677	6.42954 × 10^-4
3	5.71349 × 10^-5	0.0981418	0.00221906	0.00159942	5.89466 × 10^-4	0.00148581
Total	0.227327	0.100316	0.100079	0.00343977	0.00594311	0.00212913

Total Effective Mass

Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
2.30176	2.30176	2.30176	0.0437573	0.0848404	0.0460895

Speedline #1 Point #3

Run time information

Wall time [ hh:mm:ss ]

00:00:08

Static Analysis

Quantity	Value	Node	X-coordinate	Y-coordinate	Z-coordinate
MaxDispAbs [ mm ]	0.0201656	376	0.122250	0.0500433	0.243390
MinDispAbs [ mm ]	0	11	0.180890	0.0214616	0.123006
MaxDispX [ mm ]	0.0167965	376	0.122250	0.0500433	0.243390
MinDispX [ mm ]	-6.30413 × 10^-5	178	0.163629	0.00461017	0.0978689
MaxDispY [ mm ]	0.0102523	375	0.123549	0.0457225	0.245396
MinDispY [ mm ]	-0.00772214	130	0.122250	0.0263101	0.00839830
MaxDispX [ mm ]	0.00716121	213	0.120908	-0.108990	0.0716595
MinDispZ [ mm ]	-0.00907005	48	0.123549	0.124115	0.122002
MaxMises [ MPa ]	2.57573	8657	0.137731	0.00523635	0.203099
MinMises [ MPa ]	1.37185 × 10^-7	12183	0.180890	-0.0221713	0.126877
MaxPrincipleStress [ MPa ]	2.42903	12727	0.136155	-0.00478628	0.153782
MinPrincipleStress [ MPa ]	-2.91686	8657	0.137731	0.00523635	0.203099

Frequency Analysis

Mode Nr.	Eigenvalue	Frequency - Real Part	Frequency - Imaginary Part
1	3.83206 × 10⁷	6190.37	0
2	3.90604 × 10⁷	6249.84	0
3	3.90996 × 10⁷	6252.97	0

Participation Factor

Mode Nr.	Eigenvalue	Frequency - Real Part	Frequency - Imaginary Part
1	3.83206 × 10⁷	6190.37	0
2	3.90604 × 10⁷	6249.84	0
3	3.90996 × 10⁷	6252.97	0

Effective Modal Mass

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	0.226793	4.36383 × 10^-5	1.67659 × 10^-4	0.00182037	0.00407777	2.98145 × 10^-7
2	4.74304 × 10^-4	0.00588066	0.0937857	6.49987 × 10^-5	0.00143877	4.59139 × 10^-4
3	2.66451 × 10^-5	0.0943324	0.00607474	0.00155207	4.26202 × 10^-4	0.00167198
Total	0.227294	0.100257	0.100028	0.00343744	0.00594274	0.00213142

Total Effective Mass

Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
2.30176	2.30176	2.30176	0.0437573	0.0848404	0.0460895

Speedline #1 Point #4

Run time information

Wall time [ hh:mm:ss ]

00:00:08

Static Analysis

Quantity	Value	Node	X-coordinate	Y-coordinate	Z-coordinate
MaxDispAbs [ mm ]	0.0158515	376	0.122250	0.0500433	0.243390
MinDispAbs [ mm ]	0	11	0.180890	0.0214616	0.123006
MaxDispX [ mm ]	0.0131361	376	0.122250	0.0500433	0.243390
MinDispX [ mm ]	-5.62650 × 10^-5	9953	0.163932	0.00483746	0.0954152
MaxDispY [ mm ]	0.00816890	375	0.123549	0.0457225	0.245396
MinDispY [ mm ]	-0.00418935	130	0.122250	0.0263101	0.00839830
MaxDispX [ mm ]	0.00507593	213	0.120908	-0.108990	0.0716595
MinDispZ [ mm ]	-0.00539927	48	0.123549	0.124115	0.122002
MaxMises [ MPa ]	2.04100	11300	0.147579	-7.19378 × 10^-4	0.160041
MinMises [ MPa ]	8.78019 × 10^-8	13882	0.180890	-0.0189185	0.117831
MaxPrincipleStress [ MPa ]	2.06484	12727	0.136155	-0.00478628	0.153782
MinPrincipleStress [ MPa ]	-2.36909	19467	0.150471	-0.00190479	0.153700

Frequency Analysis

Mode Nr.	Eigenvalue	Frequency - Real Part	Frequency - Imaginary Part
1	3.83224 × 10⁷	6190.51	0
2	3.90558 × 10⁷	6249.47	0
3	3.90982 × 10⁷	6252.85	0

Participation Factor

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	-0.476239	-0.00664538	0.0134377	0.0426671	-0.0639040	5.86797 × 10^-4
2	0.0223327	-0.0618187	0.310429	0.00612101	-0.0368556	0.0233671
3	-0.00605597	0.310396	0.0628863	-0.0397541	0.0224929	0.0397890

Effective Modal Mass

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	0.226804	4.41611 × 10^-5	1.80572 × 10^-4	0.00182048	0.00408372	3.44331 × 10^-7
2	4.98751 × 10^-4	0.00382155	0.0963664	3.74667 × 10^-5	0.00135833	5.46022 × 10^-4
3	3.66748 × 10^-5	0.0963455	0.00395469	0.00158039	5.05932 × 10^-4	0.00158316
Total	0.227339	0.100211	0.100502	0.00343834	0.00594798	0.00212953

Total Effective Mass

Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
2.30176	2.30176	2.30176	0.0437573	0.0848404	0.0460895

Speedline #1 Point #5

Run time information

Wall time [ hh:mm:ss ]

00:00:08

Static Analysis

Quantity	Value	Node	X-coordinate	Y-coordinate	Z-coordinate
MaxDispAbs [ mm ]	0.0135710	376	0.122250	0.0500433	0.243390
MinDispAbs [ mm ]	0	11	0.180890	0.0214616	0.123006
MaxDispX [ mm ]	0.0112292	376	0.122250	0.0500433	0.243390
MinDispX [ mm ]	-6.00150 × 10^-5	99	0.164490	0.0460013	0.120191
MaxDispY [ mm ]	0.00702263	375	0.123549	0.0457225	0.245396
MinDispY [ mm ]	-0.00274241	131	0.120908	0.0215674	0.00814328
MaxDispX [ mm ]	0.00382459	214	0.119520	-0.109992	0.0763221
MinDispZ [ mm ]	-0.00388027	379	0.118083	0.0607928	0.234123
MaxMises [ MPa ]	1.79623	11300	0.147579	-7.19378 × 10^-4	0.160041
MinMises [ MPa ]	5.85553 × 10^-8	13882	0.180890	-0.0189185	0.117831
MaxPrincipleStress [ MPa ]	1.83183	12727	0.136155	-0.00478628	0.153782
MinPrincipleStress [ MPa ]	-2.09163	19467	0.150471	-0.00190479	0.153700

Frequency Analysis

Mode Nr.	Eigenvalue	Frequency - Real Part	Frequency - Imaginary Part
1	3.83224 × 10⁷	6190.51	0
2	3.90615 × 10⁷	6249.92	0
3	3.90980 × 10⁷	6252.84	0

Participation Factor

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	-0.476193	-0.00682664	0.0139540	0.0426882	-0.0639698	6.14849 × 10^-4
2	0.0228240	-0.0539541	0.311113	0.00502620	-0.0361129	0.0243618
3	-0.00668622	0.311805	0.0553867	-0.0398750	0.0233651	0.0391940

Effective Modal Mass

Mode Nr.	Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
1	0.226760	4.66030 × 10^-5	1.94715 × 10^-4	0.00182229	0.00409213	3.78039 × 10^-7
2	5.20936 × 10^-4	0.00291105	0.0967914	2.52627 × 10^-5	0.00130414	5.93497 × 10^-4
3	4.47055 × 10^-5	0.0972221	0.00306768	0.00159002	5.45928 × 10^-4	0.00153617
Total	0.227326	0.100180	0.100054	0.00343757	0.00594220	0.00213004

Total Effective Mass

Translation X	Translation Y	Translation Z	Rotation X	Rotation Y	Rotation Z
2.30176	2.30176	2.30176	0.0437573	0.0848404	0.0460895
